Schneider TSXETY4102 Ethernet 10/100 TCP/IP Module
Product Overview
The Schneider TSXETY4102 Ethernet 10/100 TCP/IP Module is a high-performance communication module designed to provide fast and reliable Ethernet communication for Modicon PLCs. It supports 10/100 Mbps Ethernet connectivity, offering flexibility in network speed and ensuring seamless integration with external devices. Ideal for industrial automation applications, the TSXETY4102 enhances network performance, enabling real-time data exchange and facilitating system scalability in Ethernet-based control systems.
Key Features
-
10/100 Mbps Ethernet Connectivity: Supports both 10 Mbps and 100 Mbps Ethernet communication, offering flexibility to suit different network requirements.
-
High-Speed Communication: Ensures fast and reliable data exchange, enhancing the overall performance of the automation system.
-
Seamless Integration: Easily integrates with Modicon PLCs and other automation devices, simplifying network setup and reducing installation time.
-
Enhanced Diagnostics: Equipped with diagnostic LEDs for real-time status monitoring, allowing quick identification of any network issues.
-
Industrial Durability: Designed for reliable operation in industrial environments, providing stable performance in harsh conditions.
-
Compact Design: Features a small footprint for easy installation in control panels and automation racks, saving valuable space.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 55 × 180 × 260 mm |
| Weight | 0.5 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | TSXETY4102 |
| Part Number | 140A0201 |
| Module Type | Ethernet 10/100 TCP/IP Communication Module |
| Network Interface | Ethernet (RJ45) |
| Protocol Supported | TCP/IP |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Input Voltage | 24 V DC |
| Power Consumption | < 5 W |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | Modicon PLC Systems |
| Communication Protocol | TCP/IP |
| Software Configuration | Schneider Electric Configuration Software |
Industry Applications
-
Industrial Automation: Ideal for connecting PLCs and other control devices over Ethernet in industrial control networks.
-
Factory Automation: Supports fast data exchange for manufacturing processes, enhancing system performance and reducing downtime.
-
Building Automation: Used in building control systems for efficient management of HVAC, lighting, and security systems.
-
Energy Management: Facilitates communication between control systems and energy management software, allowing for more efficient use of energy resources.
The Schneider TSXETY4102 Ethernet 10/100 TCP/IP Module offers high-speed communication for Modicon PLC systems, ensuring seamless integration with other networked devices. Its flexible 10/100 Mbps Ethernet capabilities and ease of installation make it an ideal choice for industries requiring reliable and efficient network connectivity in industrial automation environments.
