Schneider TSXETY4103 Ethernet TCP/IP Module
Product Overview
The Schneider TSXETY4103 Ethernet TCP/IP Module is a high-performance communication module developed for seamless Ethernet integration with Modicon Premium PLCs. Supporting advanced networking features and high-speed communication, it enables real-time data exchange and remote diagnostics across industrial networks. This module enhances automation system flexibility and connectivity, making it ideal for scalable, Ethernet-based industrial applications.
Key Features
-
Advanced TCP/IP Communication: Supports reliable Ethernet communication at 10/100 Mbps, ideal for high-demand control systems.
-
Seamless PLC Integration: Designed for compatibility with Modicon Premium PLCs, enabling plug-and-play installation and configuration.
-
Enhanced Security Features: Offers password protection and network filtering for secure communications.
-
Real-Time Diagnostics: Includes diagnostic LEDs and web server functions for real-time monitoring and remote troubleshooting.
-
Flexible Protocol Support: Compatible with Modbus TCP, SNMP, FTP, and HTTP protocols, expanding system interoperability.
-
Rugged Industrial Design: Built to perform in harsh industrial environments, with resistance to temperature and humidity variations.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | Package size 55 × 180 × 260 mm |
| Weight | 0.34 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | TSXETY4103 |
| Part Number | 140NOE77111 (varies by config) |
| Module Type | Ethernet TCP/IP Communication Module |
| Network Interface | Dual RJ45 Ports |
| Protocol Supported | TCP/IP, Modbus TCP, SNMP, FTP, HTTP |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Input Voltage | 24 V DC |
| Power Consumption | < 5 W |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | Modicon Premium PLC Systems |
| Communication Protocol | TCP/IP, Modbus TCP |
| Software Configuration | Schneider Unity Pro / EcoStruxure |
Industry Applications
-
Industrial Control Systems: Enables Ethernet communication between PLCs and SCADA or MES systems for streamlined automation.
-
Manufacturing Plants: Facilitates fast, real-time control and monitoring for assembly lines and robotic systems.
-
Infrastructure Automation: Supports energy distribution, water treatment, and transportation systems via secure and scalable networks.
-
Remote Monitoring Solutions: Allows for web-enabled diagnostics, reducing on-site maintenance and improving uptime.
The Schneider TSXETY4103 Ethernet TCP/IP Module delivers robust, secure, and high-speed networking capabilities to Modicon Premium PLC systems. Its support for multiple protocols, advanced diagnostics, and industrial-grade design make it a reliable component in modern industrial automation infrastructures.
