Siemens 6AG1138-6DB00-2BB1 Pulse Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Description |
|---|---|
| Brand | Siemens |
| Model | 6AG1138-6DB00-2BB1 |
| Product Type | SIPLUS ET 200SP TM Pulse 2x24V Pulse Output Module |
| Product Series | SIPLUS ET 200SP |
| Base Model | 6ES7138-6DB00-0BB1 |
| Main Function | Pulse output, PWM control and frequency generation |
| Number of Channels | 2 |
| Rated Output Voltage | 24 V DC |
| Permissible Load Voltage Range | 19.2–28.8 V DC |
| Maximum Output Current | 2 A per channel with suitable operating mode and load conditions |
| Output Type | P-switching and M-switching |
| Pulse Output Functions | Single pulse, pulse train and frequency output |
| PWM Function | Supported on both channels |
| PWM Duty Cycle | 0–100% |
| Maximum Configurable PWM Cycle Duration | 85 s |
| Minimum Pulse Duration | 1.5 μs in high-speed mode; 10 μs in standard mode |
| Pulse Duration Accuracy | ±100 ppm ±0.5 μs in high-speed mode; ±100 ppm ±9 μs in standard mode |
| Digital Inputs | 2, one per channel |
| Digital Input Rated Voltage | 24 V DC |
| Digital Input Signal “0” | −30 to +5 V |
| Digital Input Signal “1” | +11 to +30 V |
| Input Functions | General-purpose input and hardware enable for digital output |
| Control Applications | Proportional valves and DC motors |
| Additional Functions | Current measurement, current control, dithering, ON-delay and OFF-delay |
| Rated Supply Voltage | 24 V DC |
| Maximum Current Consumption | 70 mA, without load |
| Typical Power Dissipation | 1.7 W |
| Encoder/Auxiliary Supply | Shared 24 V DC supply for both channels |
| Maximum Auxiliary Output Current | 300 mA |
| Protection Functions | Short-circuit protection and reverse-polarity protection |
| Diagnostic Functions | Diagnostic alarms and module status monitoring |
| Isochronous Mode | Supported |
| Firmware Update | Supported |
| Compatible BaseUnit | BU Type B1 |
| PROFINET Engineering | GSDML V2.31 or later supported version |
| PROFIBUS Engineering | GSD Revision 5 or later supported version |
| Protective Coating | Conformal coating |
| Operating Temperature | −40 to +60°C, depending on mounting orientation and derating conditions |
| Degree of Protection | IP20 |
| Dimensions | 20 × 73 × 58 mm |
| Weight | 0.05 kg |
FAQ
Q1: What is the main function of the Siemens 6AG1138-6DB00-2BB1?
The Siemens SIPLUS ET 200SP TM Pulse 2x24V module generates pulse and PWM signals for industrial control applications. It is designed primarily for controlling proportional valves and DC motors, supporting precise output timing and configurable pulse patterns within a SIMATIC ET 200SP automation system.
Q2: How many output channels does this module provide?
The module has two independent pulse output channels. Each channel supports a range of configurable output functions, including pulse generation, pulse trains, frequency output and PWM. The maximum output current is 2 A per channel under the specified operating conditions.
Q3: What is the difference between pulse output and PWM output?
Pulse output generates individual pulses or a defined sequence of pulses. PWM varies the ratio between the ON and OFF periods to control the effective output delivered to a load. PWM is commonly used for proportional valve control and DC motor applications where adjustable output duty cycle is required.
Q4: Can this module control proportional valves and DC motors?
Yes. The module is designed for both applications. For proportional valves, it supports PWM control and configurable dithering to help reduce friction-related effects in suitable valve systems. For DC motors, pulse and PWM functions can be used for control, provided the motor and output circuit meet the module’s electrical requirements.
Q5: What power supply and load conditions are required?
The module uses a nominal 24 V DC load supply, with an allowable range of 19.2–28.8 V DC. Each output can handle up to 2 A under the specified conditions. Check the load’s starting current, inductive characteristics, wiring and protective measures before connecting the equipment.
Q6: What is the purpose of the two digital inputs?
Each output channel has one configurable digital input. Depending on the application configuration, an input can be used as a general-purpose signal or as a hardware enable for the corresponding digital output. This enables external signals to influence output operation without relying solely on the PLC program cycle.
Q7: Why might the pulse or PWM output fail to operate correctly?
Common causes include an incorrect load supply, output overload, short circuit, incorrect channel configuration, unsuitable pulse parameters or wiring errors. Check the 24 V DC supply, output load, digital input states and PLC diagnostics. Also verify that the selected operating mode and pulse timing are suitable for the connected device.
Q8: What should be checked when commissioning or replacing this module?
Confirm compatibility with the SIMATIC ET 200SP station and BU Type B1 BaseUnit. Verify the load supply, channel wiring, current requirements, output mode, PWM period, duty cycle and any current-control or dithering settings. Test both channels independently and confirm that the connected valve or motor responds correctly before returning the equipment to normal operation.
Siemens 6AG1138-6DB00-2BB1 Pulse Output Module is in stock. Please contact us for a quick quote and competitive pricing.
