Yokogawa AAI543-S00 Analog Output Modules
1. Product Overview
The Yokogawa AAI543-S00 Analog Output Module is a high-performance module designed for controlling and regulating analog output signals in Yokogawa’s Distributed Control Systems (DCS), such as CENTUM VP and ProSafe-RS. This module is ideal for a wide range of applications that require precise, real-time analog signal output for process control.
Supporting 4-20 mA and 0-10V output signals, the AAI543-S00 is engineered to provide high reliability and accuracy in demanding industrial environments, such as petrochemical, power generation, water treatment, and manufacturing sectors. The module also offers flexible integration with Yokogawa DCS systems, ensuring seamless operation and system reliability in safety-critical applications.
2. Key Features
-
High Precision Output: 16-bit D/A conversion ensures accurate and stable output signals for precise control.
-
Wide Signal Compatibility: Supports standard 4-20 mA and 0-10V output signals, providing flexibility for different process control requirements.
-
Channel Isolation: Electrical isolation between output channels improves safety and prevents interference between outputs.
-
Robust Design: Engineered for use in harsh industrial environments with protection against electrical noise and other environmental factors.
-
Hot Swappable: Modules can be replaced without shutting down the system, ensuring minimal downtime and enhanced operational availability.
-
Built-in Diagnostics: Features diagnostics for real-time fault detection and operational monitoring, ensuring system health and reliability.
-
Seamless System Integration: Fully compatible with Yokogawa’s CENTUM VP and ProSafe-RS systems for easy integration into existing setups.
3. Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.4 kg |
3.2 General Information
| Item | Specification |
|---|---|
| Model | AAI543-S00 |
| Manufacturer | Yokogawa Electric Corporation |
| Installation | DIN rail or rack-mounted |
| Power Supply | Supplied via system backplane |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -20°C to +70°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
3.3 Output Performance
| Item | Specification |
|---|---|
| Analog Outputs | 8 channels |
| Signal Types | 4-20 mA, 0-10V |
| Resolution | 16-bit D/A converter |
| Accuracy | ±0.1% F.S. |
| Output Impedance | Approx. 250 Ω (current output) |
| Output Load | Up to 750 Ω (current output) |
| Channel Isolation | Yes |
| Update Rate | ≤100 ms |
3.4 Electrical Characteristics
| Item | Specification |
|---|---|
| Power Supply | 24 V DC ±10% (via backplane) |
| Power Consumption | Max 3.5 W |
| Operating Current | ≤ 0.15 A |
| Status Indicators | LEDs for power, run, fault |
4. Industry Applications
The Yokogawa AAI543-S00 Analog Output Module is widely used in various industrial sectors that require accurate and reliable analog control signals:
-
Oil & Gas: Ensures precise control of process variables in upstream and downstream oil and gas operations.
-
Chemical & Pharmaceutical: Used for precise dosing and regulation of chemicals in processing plants.
-
Power Generation: Regulates analog signals for turbines, generators, and boilers in power plants.
-
Water Treatment: Provides real-time control of flow rates, chemical dosing, and other critical parameters in water treatment processes.
-
Manufacturing & Metallurgy: Enhances automation control in industrial production lines, improving product quality and efficiency.
The AAI543-S00 module is integral to Yokogawa’s DCS solutions, providing reliable analog output control for safety-critical and high-performance applications in a variety of industries.
Yokogawa AAI543-s00 Analog Output Modules is in stock. Please contact us for a quick quote and competitive pricing.
