Product Overview
The ADV561-P50 S2 is a high-density, 64-channel isolated digital output module designed for integration into Yokogawa field I/O racks or node bases within distributed control and safety instrumented systems. The “P50” suffix indicates that this module supports one-shot pulse width output and time-proportional output functions. The “S2” suffix denotes a specific revision or variant version.
This module delivers 24 V DC current-sink type transistor outputs, making it ideal for controlling field devices such as relays, solenoids, lamps, alarms and other digital output loads in industrial automation environments.
Key Features
-
64 independent isolated digital output channels at 24 V DC.
-
Output format: current-sink type, meaning field loads are tied to +24 V and module sinks the return.
-
Pulse-width and time-proportional output functionality, with one-shot pulses and time-proportioned ON/OFF control.
-
High isolation capability between output circuits and system bus for reliability in harsh environments.
-
Compact and lightweight plug-in module design suitable for high-density field-I/O racks.
-
Compatible with dual redundant configurations (module pairs) for high-availability installations.
Technical Specifications
| Parameter | Specification / Description |
|---|---|
| Model Number | ADV561-P50 S2 |
| Product Family | Yokogawa ADV561 Series Digital Output Module (64-channel) |
| Number of Output Channels | 64 channels |
| Rated Applied Field Voltage | 24 V DC |
| External Field-Supply Voltage Range | 20.4 V DC to 26.4 V DC |
| Output Format | Current-sink transistor output |
| Maximum Load Current per Channel | 100 mA (at 26.4 V DC) |
| Maximum Output ON Voltage | ≤ 2 V DC |
| Leakage Current (Output OFF) | ≤ 0.1 mA |
| Output Response Time | ≤ 3 ms (status output) / ≤ 10 ms (mixed status + pulse outputs) |
| Pulse Width Output Range | 8 ms to 7,200 s (time-proportional ON/OFF) |
| Withstanding Voltage | • Between output signal and system: 2 kV AC for 1 minute • Between commons (– side every 16 channels): 500 V AC for 1 minute |
| Operating Ambient Temperature | Approx. –20 °C to +70 °C |
| Relative Humidity | Up to 95 % (non-condensing) |
| Mounting Type | Plug-in module for Yokogawa field I/O rack or node base |
| Dimensions (Approx.) | Height ≈ 130 mm × Depth ≈ 100 mm × Width ≈ 30 mm |
| Weight (Approx.) | ≈ 0.30 kg |
