Yokogawa ADV569-P00 Digital I/O Modules
Product Overview
The Yokogawa ADV569-P00 is a 64-channel digital I/O module designed for use with Yokogawa’s CENTUM-ST distributed control systems (DCS). This module provides reliable and high-density digital input and output capabilities, making it ideal for controlling and monitoring a wide range of field devices in industrial automation applications. Its high channel density and robust features ensure efficient control in industries requiring precise signal processing, such as power generation, chemical processing, and process control.
Key Features
-
64 I/O Channels – Provides 64 independent input/output channels, enabling the management of a large number of field devices simultaneously.
-
Signal Isolation – Channels are electrically isolated to improve noise immunity and protect the system from voltage spikes.
-
Transistor Contact Output – Uses transistor contact outputs, making it suitable for controlling relays, solenoids, and actuators.
-
Input Voltage Range – Supports a wide input voltage range, ensuring compatibility with various industrial environments.
-
Fast Response Time – Ensures quick signal processing with an output response time of 16 ms or less, critical for time-sensitive applications.
-
Wide Pulse Width Range – Supports pulse widths from 8 ms to 7200 seconds with 8 ms resolution, providing flexibility in signal generation.
-
Energy-Efficient – Consumes approximately 570 mA at 5 V DC, optimizing energy consumption in the system.
-
External Connection – Uses a dedicated cable (KS2) for easy installation and maintenance.
-
Compatibility – Fully compatible with Yokogawa’s CENTUM-ST systems, using the ST4 card for seamless integration.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 130 x 127.2 x 32.8 mm |
| Weight | 0.3 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Number of I/O Channels | 64 |
| Signal Isolation | Electrically isolated channels |
| Output Signal | Transistor contact output |
| Output Contact Rating | Inductive load, resistive load: 30 V DC, 100 mA |
| Output Response Time | 16 ms or less |
| Pulse Width | 8 ms to 7200 s |
| Pulse Width Resolution | 8 ms, with maximum ON/OFF delay of 1 ms |
| Maximum Current Consumption | 570 mA (5 V DC) |
| External Connection | Dedicated cable (KS2) |
| Compatible Card | ST4 compatible |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 10%–90% RH (non-condensing) |
| Vibration | 0.05 g rms, 10 to 500 Hz |
| Shock | 5 g, 20 ms half-sine wave |
| Protection | IP20 (when installed in an enclosure) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Platform | Yokogawa CENTUM-ST DCS |
| Compatible Modules | ST4 card |
Industry Applications
-
Process Control – Managing digital signals in complex process control systems to ensure accurate and timely responses.
-
Power Generation – Controlling field devices in power plants to enhance operational efficiency and safety.
-
Chemical Processing – Handling digital outputs from various sensors and switches to maintain process integrity and safety.
-
Oil and Gas – Monitoring and controlling critical field devices in upstream and downstream operations to ensure operational reliability.
-
Water and Wastewater Treatment – Ensuring accurate digital signal monitoring in treatment facilities to aid in compliance and efficiency.
The Yokogawa ADV569-P00 Digital I/O Modules provide a reliable and high-density solution for digital signal processing in industrial automation systems. With their robust design, fast response time, and seamless integration with Yokogawa’s CENTUM-ST systems, these modules are ideal for applications requiring dependable and efficient digital I/O capabilities.
Yokogawa ADV569-P00 Digital I/O Modules is in stock. Please contact us for a quick quote and competitive pricing.
