Product Overview
The ADV869-P01 is a high-density isolated digital I/O module engineered for use with the Yokogawa ST5-compatible field I/O (FIO) and distributed control system platforms. It supports 32 digital input channels and 32 digital output channels in a single module, with isolation grouped every 16 channels. The “P” suffix indicates support for pulse-width and/or time-proportional output functions; the “01” suffix denotes a specific revision or option set.
This module is intended for industrial automation environments where compact footprint, high channel count, reliable isolation and advanced output timing capability are required.
Technical Specifications
| Parameter | Specification / Description |
|---|---|
| Model Number | ADV869-P01 |
| Channel Configuration | 32 digital input channels + 32 digital output channels |
| Signal Isolation | Common minus side every 16 channels |
| Input – Contact Type | OFF signal: ≥ 100 kΩ ON signal: ≤ 200 Ω Minimum short-circuit current: ~1.25 mA |
| Input – Voltage Type | OFF: 4.5 – 25 V DC ON: ±1 V difference at ≤ 200 Ω load |
| Input Contact Rating | ≥ 5 V DC, ≥ 20 mA |
| Input Response Time | ≤ 8 ms (for status input) |
| Output – Type | Transistor contact (current-sink format) |
| Output Contact Rating | 30 V DC, 100 mA (resistive/inductive) |
| Output Response Time | ≤ 16 ms |
| Pulse-Width / Time-Proportional Output Range | 8 ms to 7 200 s Resolution: 8 ms + max. 1 ms ON/OFF delay |
| Maximum Current Consumption | Approx. 800 mA at 5 V DC |
| Dimensions (Approximate) | Height: ~130 mm Depth: ~100 mm Width: ~30 mm |
| Weight (Approximate) | ~0.30 kg |
| Operating Ambient Temperature | –20 °C to +70 °C |
| Relative Humidity | Up to 95 % RH (non-condensing) |
| External Connection | Dedicated cable or KS-type connector |
| System Compatibility | ST5 compatible |
