Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AFV30D-A400 |
| Type | Duplexed Field Control Unit (for Vnet/IP and FIO, 19-inch rack mountable) |
| Processor | VR5532 (approx. 350 MHz) |
| Main Memory Capacity | 128 MB |
| Memory Retention (Battery Backup) | Up to 72 hours |
| Communication Interface | Dual-redundant Vnet/IP |
| Number of Node Units Connectable | Up to 13 per FCU |
| Power Supply Options | Dual-redundant power supply modules |
| Operating Temperature Range | -10 °C to +55 °C |
| Weight | Approx. 8.0 kg |
| External Dimensions | Width ≈ 482.6 mm × Depth ≈ 465.1 mm × Height ≈ 207 mm |
| Mounting | 19-inch rack mount, secured with M5 screws |
FAQ
Q1: What does the suffix “-A400” in AFV30D-A400 represent?
A1: The suffix “A400” designates a specific variant of the AFV30D family: “A” for standard type (CP471 platform), and “400” indicating dual-redundant network & power supply with the base revision.
Q2: Can the AFV30D-A400 model support redundant operation for both communication and power?
A2: Yes. The “D” in AFV30D indicates duplexed architecture with dual-redundant Vnet/IP communication and dual power supply modules, providing high system availability.
Q3: What are the physical dimensions and weight of the AFV30D-A400?
A3: The unit measures approximately 482.6 mm wide, 465.1 mm deep, and 207 mm high, and it weighs about 8.0 kg.
Q4: How many node units can be connected to this FCU?
A4: The AFV30D-A400 supports connection of up to 13 node units (for ESB/optical ESB bus) per field control unit.
Q5: What are its power supply and environmental capabilities?
A5: It features a dual-redundant power supply system, supports operation from approx. -10 °C to +55 °C, and offers battery backup for memory retention of up to 72 hours.
Q6: Is this unit suitable for mission-critical industrial process control environments?
A6: Yes — given its duplexed design, redundancy in communication and power, and robust memory backup, it is built for high-availability control installations.
Q7: Which processor and memory capacity does the AFV30D-A400 use?
A7: It uses a VR5532 processor (≈ 350 MHz) and 128 MB main memory, providing ample processing and storage capacity for control tasks.
Q8: Where can I find detailed installation and configuration guidance for this unit?
A8: Manufacturer’s hardware specification documents, installation guides and suffix-code interpretation sheets are available from the control system provider’s documentation library for the AFV30D series.
