Allen-Bradley 20G11BC1K2AN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Series | PowerFlex 755 |
| Product Type | AC Drive |
| Catalog Number | 20G11BC1K2AN0NNNNN |
| Input Voltage | 400 VAC |
| Input Phase | 3 Phase |
| Rated Current | 1175 A |
| Low Duty Rating | 800 kW |
| Normal Duty Rating | 710 kW |
| Heavy Duty Rating | 560 kW |
| Frame Size | Frame 9 |
| Cooling | Air Cooled |
| Communication | Embedded EtherNet/IP |
| Input Configuration | AC Input with DC Terminals |
| Enclosure | Type 1, IP20 |
| Cabinet Depth | 600 mm, MCC Style |
| EMC Filtering | Filtered |
| CM Jumper | Removed |
| Dynamic Braking | None |
| HIM | Blank / No HIM |
| Dimensions | 145 mm × 140 mm × 140 mm |
| Weight | 2.5 kg |
The 20G11BC1K2AN0NNNNN is a high-power Allen-Bradley PowerFlex 755 AC drive rated for 400 VAC three-phase operation. The catalog description specifies 1,175 A, 800 kW low-duty, 710 kW normal-duty, and 560 kW heavy-duty ratings. It uses embedded EtherNet/IP, air cooling, filtered input, DC terminals, and a 600 mm-deep MCC-style Type 1/IP20 enclosure.
This configuration has the CM jumper removed and does not include a dynamic-braking option or HIM. The model is listed as a Frame 9 PowerFlex 755 configuration.
FAQ
Q1: What is the Allen-Bradley 20G11BC1K2AN0NNNNN?
A1: It is a high-power PowerFlex 755 AC drive designed for industrial motor speed and torque control in demanding applications.
Q2: What input voltage does this drive use?
A2: The 20G11BC1K2AN0NNNNN is rated for 400 VAC, three-phase input power.
Q3: What is the current rating of this model?
A3: The rated current is 1,175 A, making it suitable for large industrial motor-drive systems.
Q4: What are the power ratings?
A4: The drive is rated at 800 kW for low-duty applications, 710 kW for normal duty, and 560 kW for heavy-duty operation.
Q5: Does the 20G11BC1K2AN0NNNNN have EtherNet/IP communication?
A5: Yes. Embedded EtherNet/IP is included in this catalog configuration, providing an integrated network interface for compatible control architectures.
Q6: What type of enclosure does it use?
A6: The drive uses a Type 1, IP20, 600 mm-deep MCC-style enclosure. It is an air-cooled configuration intended for installation in an appropriate industrial control environment.
Q7: Does this model include dynamic braking or a HIM keypad?
A7: No. The catalog configuration specifies no dynamic-braking option and a blank/no-HIM arrangement.
Q8: What should be considered when checking the physical size and weight?
A8: Because this is a large Frame 9 MCC-style PowerFlex 755 configuration, installation space, cabinet arrangement, cable entry, ventilation, and lifting requirements should be checked against the applicable installation documentation. The catalog description confirms the 600 mm cabinet-depth configuration, while the final overall dimensions and shipping weight depend on the complete configured assembly.
Allen-Bradley 20G11BC1K2AN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
