Allen Bradley MPL-A230P-HJ74AA Servo Motor
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Model | MPL-A230P-HJ74AA |
| Product Type | Low-Inertia AC Servo Motor |
| Product Series | MP-Series MPL |
| Voltage Rating | 230 V AC |
| Voltage Class | 200 V AC |
| Frame Size | 75 mm |
| Magnet Stack Length | 76.2 mm |
| Rated Speed | 5000 rpm |
| Maximum Speed | 5000 rpm |
| Continuous Rated Power | 0.86 kW |
| Continuous Stall Torque | 2.1 Nm |
| Peak Torque | 8.2 Nm |
| Feedback Type | Incremental Encoder |
| Feedback Resolution | 2000 pulses/revolution |
| Shaft Type | Keyed Shaft Extension |
| Holding Brake | 24 V DC Brake |
| Connector Type | SpeedTEC DIN Connector |
| Connector Orientation | Right-Angle, Rotatable 180° |
| Mounting Type | IEC Metric Flange Mount |
| Mounting Holes | Free Mounting Holes, Type FF |
| Shaft Seal | No |
| Protection Rating | IP50 |
| Operating Temperature | 0–40°C |
| Weight | 2.6 kg |
FAQ
1. What applications is the Allen-Bradley MPL-A230P-HJ74AA servo motor suitable for?
The MPL-A230P-HJ74AA is designed for industrial motion-control applications requiring precise speed regulation and repeatable positioning. Typical uses include packaging machinery, automated assembly lines, material handling equipment, and production systems. Its low-inertia design supports responsive acceleration and deceleration, while the appropriate servo drive enables closed-loop control based on the machine’s motion requirements.
2. Which servo drives are compatible with the MPL-A230P-HJ74AA?
Compatibility depends on the exact servo drive model, voltage class, encoder interface, and motor configuration. Before installation, confirm that the selected Allen-Bradley Kinetix or Ultra drive explicitly supports this motor catalog number. Checking the manufacturer’s compatibility documentation helps prevent feedback errors and commissioning problems.
3. What type of feedback does the MPL-A230P-HJ74AA use?
This motor is specified with an incremental encoder. The encoder supplies position and speed feedback to the servo drive, allowing the controller to regulate motion and correct deviations from the commanded position. Reliable operation depends on proper feedback wiring, signal integrity, and correct drive configuration.
4. How does the integrated 24 V DC brake work?
The integrated brake is intended to hold the motor shaft when the motor is stopped and the brake is engaged. The brake must be controlled according to the manufacturer’s specified electrical and operating requirements. It should not be assumed suitable for repeated dynamic stopping unless explicitly approved for that purpose. Applications involving vertical axes or suspended loads also require an appropriate safety assessment.
5. What should be checked before commissioning the motor?
Verify the motor catalog number, drive compatibility, supply requirements, encoder connection, and brake-control wiring. Inspect the power cable, connectors, grounding, mechanical coupling, and mounting alignment. Configure the drive with the correct motor parameters and follow the manufacturer’s startup procedure. Initial movement tests should be performed under controlled conditions before normal production operation.
6. What can cause the motor to trigger a servo drive alarm?
Possible causes include encoder signal loss, loose connectors, power supply irregularities, excessive load, incorrect motor parameters, or a brake that fails to release correctly. Check the drive alarm code first, then inspect the electrical connections and mechanical load. Avoid replacing the motor until the fault has been isolated, since wiring or drive configuration problems can produce similar symptoms.
7. How can unstable movement or positioning errors be corrected?
Start by checking encoder feedback, cable condition, mechanical coupling, load alignment, and servo tuning. Excessive backlash, vibration, sudden load changes, or incorrect feedback configuration can cause inaccurate positioning. Review the drive’s alarm history and verify the configured motor data. Make controlled tuning adjustments in accordance with the drive manufacturer’s procedures.
8. What should be considered when replacing the MPL-A230P-HJ74AA?
The replacement should match the required voltage class, speed and torque ratings, encoder type, keyed shaft, connector arrangement, and 24 V DC brake configuration. Compatibility with the existing servo drive and control system must also be confirmed. Motors with similar model numbers may differ in feedback or brake options, so verify the complete catalog number before ordering or commissioning a replacement.
Allen Bradley MPL-A230P-HJ74AA Servo Motor is in stock. Please contact us for a quick quote and competitive pricing.
