Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 1783-MX04T04E Stratix 8000 Expansion Module |
| Product Type | Industrial Equipment |
| Series | Stratix 8000 |
| Device Type | Ethernet Expansion Module (PoE + RJ45) |
| Network Type | Industrial Ethernet |
| Total Ports | 8 Ports |
| Copper Ports | 4 × 10/100 Mbps RJ45 Fast Ethernet |
| PoE Ports | 4 × 10/100 Mbps RJ45 PoE (Power over Ethernet) |
| Power Input | 48–54 V DC (for PoE operation) |
| Backplane Power | 3.3 V DC internal module supply |
| Maximum PoE Power Budget | Up to 62 W |
| Power Consumption | Approx. 7.9 W max |
| Isolation Voltage | 60 V continuous (industrial isolation design) |
| Mounting Type | Installed in Stratix 8000 switch chassis |
| Module Type | Add-on expansion module (not standalone) |
| Enclosure Type | Open industrial module (rack-integrated system) |
| Operating Temperature | -40°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Dimensions (H × W × D) | Approx. 148 × 98 × 117 mm |
| Weight | Approx. 0.4–0.6 kg |
| Typical Applications | Industrial PoE devices, IP cameras, PLC network expansion, machine automation Ethernet systems |
FAQ
What is the 1783-MX04T04E used for?
It is an expansion module for Stratix 8000 switches, providing additional Ethernet ports and Power over Ethernet (PoE) capability for industrial networks.
Is it a standalone switch?
No, it is not standalone. It must be installed into a compatible Stratix 8000 chassis.
How many ports does it provide?
It provides 8 ports total: 4 standard Fast Ethernet RJ45 ports and 4 PoE-enabled ports.
Does it support PoE devices?
Yes, it can power industrial devices such as IP cameras, sensors, and Ethernet-enabled field devices through PoE.
What is the maximum PoE power budget?
It supports up to approximately 62 W total PoE power output.
What environments is it designed for?
It is designed for harsh industrial environments with an operating temperature range of -40°C to 60°C.
What type of system is it compatible with?
It is compatible only with Stratix 8000/8300 series modular switch systems.
Where is it commonly used?
It is commonly used in factory automation, machine networks, industrial surveillance systems, and PLC-based Ethernet infrastructures requiring PoE expansion.
Allen Bradley 1783-MX04T04E Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
