ABB 1MRK000508-CBr00 Binary Input Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Ordering Number | 1MRK000508-CBr00 |
| Product Type | Binary Input Module |
| Number of Inputs | 16 binary inputs |
| Input Type | Digital / Binary Input |
| Rated Input Voltage | 110–125 VDC |
| Current Consumption | 30 mA |
| Typical Application | Protection, control and substation automation |
| Signal Acquisition | Digital ON/OFF status monitoring |
| Typical Signals | Circuit breaker status, disconnector position, alarms, interlocking and auxiliary contacts |
| System Application | ABB protection and control equipment |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% RH, non-condensing |
| Vibration | 0.5 g RMS, 10–500 Hz |
| Installation | Internal module/board installation |
| Dimensions | 30 × 150 × 262 mm |
| Weight | 0.4 kg |
FAQ
Q1: What is the main function of the ABB 1MRK000508-CBr00?
A: The ABB 1MRK000508-CBr00 is a 16-channel Binary Input Module designed to acquire discrete signals in protection and control systems. It receives ON/OFF status information from external equipment and transfers the signals to the associated protection system for monitoring, interlocking, alarm processing and control logic.
Q2: How many binary inputs does the 1MRK000508-CBr00 provide?
A: The module provides 16 binary input channels. Each channel can be used to monitor an independent digital signal, making the module suitable for applications where multiple switchgear or protection-related status signals need to be collected by the same protection system.
Q3: What is the rated input voltage of the 1MRK000508-CBr00?
A: The 1MRK000508-CBr00 is specified for 110–125 VDC input circuits, with a current consumption of approximately 30 mA. The external control circuit should be checked before installation to ensure that its voltage matches the module’s electrical requirements.
Q4: What types of signals can be connected to this binary input module?
A: The module is intended for discrete status signals such as circuit breaker open/closed indication, disconnector position, protection alarms, interlocking signals and auxiliary relay contacts. These signals can be used by the protection system for status monitoring and control logic.
Q5: What should be checked if a binary input does not change state?
A: Start by checking the corresponding field device and auxiliary contact. Measure the DC voltage at the input terminal and inspect the terminal wiring and common connection. If the external signal is correct but the protection system still does not detect the state change, check the I/O configuration and module status before replacing the hardware.
Q6: What should be checked if several input channels become abnormal at the same time?
A: Multiple simultaneous input failures should first be investigated through the common parts of the circuit. Check the field DC supply, common connections, terminal wiring and module connection. If the external signals are normal, inspect the module and the associated protection device for hardware or configuration problems.
Q7: What should be confirmed before replacing a 1MRK000508-CBr00?
A: Confirm the complete ordering number, 110–125 VDC input rating, 16-channel configuration and the ABB protection or control device in which the module is installed. The 1MRK000508 family contains variants with different electrical characteristics, so replacement should be based on the complete part number rather than appearance alone.
Q8: What applications are suitable for the ABB 1MRK000508-CBr00?
A: The module is suitable for binary signal acquisition in electrical protection and automation systems. Typical applications include substation automation, feeder protection, circuit breaker monitoring, switchgear status detection, alarm monitoring and interlocking. It provides the protection system with the discrete field information required for monitoring and control functions.
ABB 1MRK000508-CBr00 Binary Input Module is in stock. Please contact us for a quick quote and competitive pricing.
