ABB 1VCR017053G0001 Power Supply Board
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Ordering Number | 1VCR017053G0001 |
| Product Type | Power Supply Board / Control Interface Board |
| Product Series | ABB V-Contact VSC |
| Main Function | Provides power and control interface functions for the vacuum contactor control system |
| Compatible Equipment | ABB V-Contact VSC medium-voltage vacuum contactors |
| Control Input Voltage | 24 V DC |
| Control Input Operating Range | 18–30 V DC |
| Typical Control Current | Approx. 150 mA |
| Maximum Control Current | Approx. 300 mA |
| Coil Drive Output | Regulated DC output; voltage and current depend on the contactor configuration |
| Auxiliary Contact Interface | Dry-contact input/output for status monitoring and interlocking |
| Isolation Voltage | 2.5 kV AC |
| Operating Temperature | -25 to +70°C |
| Storage Temperature | -40 to +85°C |
| Relative Humidity | 5–95% RH, non-condensing |
| Installation | Installed inside the VSC contactor or control cabinet |
| Terminal Type | Screw terminals |
| Typical Applications | Medium-voltage motor control, transformer switching, capacitor-bank control and power distribution |
| Protection Rating | IP20 when installed inside the appropriate enclosure |
| Dimensions | 140 × 100 × 25 mm |
| Weight | 0.3 kg |
FAQ
1. What is the ABB 1VCR017053G0001 Power Supply Board used for?
The ABB 1VCR017053G0001 is a power supply and control interface board designed for V-Contact VSC medium-voltage vacuum contactor systems. It provides the required power and control functions for the contactor circuitry and supports the execution of opening and closing commands.
2. Which ABB equipment is compatible with the 1VCR017053G0001?
The 1VCR017053G0001 is primarily associated with ABB V-Contact VSC vacuum contactors. Because VSC contactors can have different control-voltage and internal circuit configurations, the exact contactor model, original board part number, and control circuit should be checked before installing a replacement.
3. What is the control input voltage of the 1VCR017053G0001?
The specified control input voltage is 24 V DC, with an operating range of approximately 18–30 V DC. Maintaining the input voltage within the specified range is important for stable operation. An insufficient voltage can prevent the control circuit from operating correctly, while excessive voltage may damage electronic components.
4. How does the 1VCR017053G0001 control the VSC vacuum contactor mechanism?
The board uses its internal control circuitry to provide controlled DC power to the contactor’s operating mechanism according to the external command signals. It can also work with auxiliary contact signals for status monitoring and interlocking, allowing the wider control system to monitor the contactor’s operating condition.
5. What are common symptoms of a faulty 1VCR017053G0001?
Possible symptoms include failure of the contactor to close or open, no response to a valid control command, abnormal status feedback, or failure of the operating mechanism to function. Troubleshooting should begin with the external 24 V DC supply, wiring, connectors, auxiliary contacts, and control signals before concluding that the board itself is defective.
6. How can the power supply circuit of the 1VCR017053G0001 be checked?
First, verify the DC input voltage at the board terminals and confirm that it is within the specified 18–30 V DC range. If the input is normal, check the board output and the wiring between the board and the operating mechanism. If the external wiring and load are normal but the output remains abnormal, the board may require further testing or replacement.
7. What precautions are required when replacing the ABB 1VCR017053G0001?
Replacement should be carried out only after the medium-voltage equipment has been safely isolated according to the applicable maintenance procedure. Verify that the control circuit is de-energized before handling the board. The ordering number, terminal connections, installation orientation, and control voltage should be checked carefully, and suitable ESD protection should be used when handling the electronic board.
8. Where is the 1VCR017053G0001 typically used?
The board is used with ABB V-Contact VSC medium-voltage vacuum contactor systems. Typical applications include industrial motor control, transformer switching, capacitor-bank control, and medium-voltage power distribution. In these systems, the board provides an important interface between the external control system and the contactor operating mechanism.
ABB 1VCR017053G0001 Power Supply Board is in stock. Please contact us for a quick quote and competitive pricing.
