ABB 3HNP01759-1 Groove Ball Bearing Assembly
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Item | Specification |
|---|---|
| Manufacturer | ABB |
| Product Type | Groove Ball Bearing Assembly |
| Ordering Number | 3HNP01759-1 |
| Product Category | Industrial Robot Spare Part |
| Bearing Type | Deep Groove Ball Bearing |
| Main Function | Provides low-friction rotational support for mechanical components |
| Typical Application | ABB industrial robot mechanical and transmission assemblies |
| Bearing Material | Bearing steel |
| Bore Diameter | 25 mm |
| Outside Diameter | 52 mm |
| Bearing Width | 15 mm |
| Dynamic Load Rating | Approx. 14.7 kN |
| Static Load Rating | Approx. 7.85 kN |
| Reference Speed | Approx. 19,000 rpm with grease lubrication |
| Seal Configuration | Open bearing |
| Operating Temperature | Approx. -20°C to +120°C |
| Application | Robot joints, rotating mechanisms, and mechanical transmission systems |
| Overall Dimensions | 85 × 40 × 12 mm |
| Weight | 0.42 kg |
FAQ
1. What is the main function of the ABB 3HNP01759-1 Groove Ball Bearing Assembly?
The 3HNP01759-1 provides rotational support between shafts and bearing housings while reducing friction during mechanical movement. It is suitable for precision mechanical assemblies used in industrial automation and robotics.
2. What type of bearing is used in the 3HNP01759-1 assembly?
The product is identified as a deep groove ball bearing assembly. This bearing type is primarily designed for radial loads and can also accommodate moderate axial loads.
3. What are the bore, outside diameter, and bearing width specifications?
The referenced bearing specification is a 25 mm bore, 52 mm outside diameter, and 15 mm bearing width. The actual shaft and housing tolerances should be checked before installation.
4. What are the dynamic and static load ratings of the 3HNP01759-1?
The referenced values are approximately 14.7 kN dynamic load rating and 7.85 kN static load rating. Actual allowable loading depends on operating speed, lubrication, alignment, duty cycle, and installation conditions.
5. What is the reference maximum speed of this bearing assembly?
With grease lubrication, the reference rotational speed is approximately 19,000 rpm. Continuous operation near the maximum speed should only be considered after evaluating temperature rise, lubrication, load, and application conditions.
6. Is the 3HNP01759-1 a sealed bearing?
The referenced configuration is an open bearing without an integral rubber seal or protective shield. Therefore, contamination control and proper lubrication are particularly important in the installation environment.
7. What operating temperature range is applicable to the 3HNP01759-1?
The referenced operating temperature range is approximately -20°C to +120°C. When used in a robot or transmission assembly with significant heat generation, the lubricant’s temperature rating should also be considered.
8. What should be checked if the bearing produces abnormal noise or excessive heat?
Check the shaft and housing fit, alignment, lubrication quantity and condition, installation force, and surrounding mechanical components. Persistent noise, vibration, or temperature rise may indicate bearing damage, raceway wear, contamination, insufficient lubrication, or mechanical misalignment.
ABB 3HNP01759-1 Groove Ball Bearing Assembly is in stock. Please contact us for a quick quote and competitive pricing.
