ABB AINT-02C 64802909A ACS800 Series Frequency Converter PCB Board
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | AINT-02C |
| Order Number | 64802909A |
| Product Type | PCB Board (Frequency Converter Interface Card) |
| Series | ACS800 Frequency Converter Series |
| Function | Control / Interface PCB Board |
| Application | Used in ABB ACS800 drive systems |
| Compatibility | ACS800 industrial frequency converters |
| Board Type | Electronic control / interface module |
| Input Voltage | Supplied by drive internal DC/logic power |
| Signal Interface | Drive control signals / feedback processing |
| Control Role | Motor control signal processing & communication |
| Mounting Method | Plug-in PCB installation inside drive |
| Operating Temperature | 0 to +55°C |
| Storage Temperature | -40 to +70°C |
| Humidity | 5%–95% (non-condensing) |
| Protection | Industrial grade electronic protection (inside drive enclosure) |
| Dimensions (W × H × D) | 140 × 110 × 60 mm |
| Weight | 0.1 kg |
FAQ
1. What is the main function of the AINT-02C PCB board?
The AINT-02C is an internal control and interface PCB used in ABB ACS800 series frequency converters. Its main function is to process control signals between the drive control system and power stage, ensuring accurate motor control, signal coordination, and stable drive operation.
2. Which drive systems is this PCB compatible with?
This board is designed specifically for ABB ACS800 series frequency converters. It is not a standalone device and must be used within compatible ACS800 drive assemblies to ensure correct functionality and system integration.
3. What role does this PCB play inside the drive?
The board acts as a critical interface between the drive’s control unit and power electronics. It processes feedback signals, manages control logic communication, and ensures that motor control commands are properly executed by the power stage.
4. Is the AINT-02C a user-replaceable component?
In most cases, it is considered a service-level internal component. Replacement should be performed by trained technicians or qualified service personnel to avoid damage to the drive system or improper installation.
5. Does this PCB directly control motor power output?
No, it does not directly supply power to the motor. Instead, it handles signal processing and communication between the control circuitry and the power section, which ultimately regulates motor voltage and frequency.
6. What happens if this PCB fails?
If the board fails, the drive may lose control functionality, resulting in fault conditions, shutdown, or inability to regulate motor operation. Proper diagnostics in ACS800 systems typically detect such failures and trigger protective shutdowns.
7. Does this board require configuration or programming?
No standalone programming is required. Configuration is handled at the drive system level. The PCB operates as part of the internal control architecture and works according to the drive’s firmware and parameter settings.
8. In what environments is this PCB typically used?
It is used in industrial environments where ACS800 drives are deployed, such as manufacturing systems, conveyors, pumps, compressors, and heavy-duty process control applications requiring reliable motor drive performance.
ABB AINT-02C 64802909A ACS800 Series Frequency Converter PCB Board is in stock. Please contact us for a quick quote and competitive pricing.
