ABB CI522AK14 3BSE018460R1 AF 100 Communication Interface
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | CI522AK14 |
| Order Number | 3BSE018460R1 |
| Product Name | AF 100 Communication Interface |
| Product Type | Advant Fieldbus 100 (AF 100) Communication Interface Kit |
| Communication Protocol | Advant Fieldbus 100 (AF 100) |
| Main Function | Provides communication connectivity between compatible industrial control system components and the AF 100 fieldbus |
| Kit Contents | CI522A interface module (3BSE018283R1), TC512V1 modem (3BSE018059R1), and TK803V036 cable (3BSC950130R2) |
| System Application | ABB Advant Master process control and compatible automation systems |
| Typical Use | Fieldbus communication, control system integration, and communication hardware replacement |
| Data Exchange | Supports communication between compatible control system components over the AF 100 network |
| Installation | Install and connect according to the system configuration and manufacturer documentation |
| Compatibility Requirements | Verify the controller configuration, fieldbus network, modem, cable, and associated hardware before installation |
| Maintenance | Inspect connectors, cables, modem connections, and communication status during scheduled maintenance |
| Replacement Requirements | Confirm the complete kit order number and included components before replacement |
| Dimensions | 148 × 45 × 117 mm |
| Weight | 0.4 kg |
FAQ
Q1: What is the ABB CI522AK14 3BSE018460R1 used for?
The ABB CI522AK14 is an AF 100 communication interface kit designed for compatible ABB Advant Master automation and process control systems. It provides the interface hardware required for communication over the Advant Fieldbus 100 network.
Q2: What components are included in the ABB CI522AK14 kit?
The kit is listed as including the CI522A interface module (3BSE018283R1), the TC512V1 modem (3BSE018059R1), and the TK803V036 cable (3BSC950130R2). Confirm the supplied components against the order documentation before installation or replacement.
Q3: What is the purpose of the AF 100 communication interface?
The AF 100 interface provides a communication path between compatible control system components. It supports the exchange of control and status information required for coordinated operation within an industrial automation system.
Q4: Which systems are compatible with the ABB CI522AK14?
The CI522AK14 is associated with ABB Advant Master process control systems. Compatibility depends on the installed controller, network architecture, interface hardware, and system revision. Check the original system documentation before connecting it to an existing network.
Q5: What should be checked before installing the CI522AK14?
Verify the order number, kit contents, controller configuration, fieldbus connections, and required modem and cable. Confirm that the installation matches the approved system design, and follow the applicable electrical safety and commissioning procedures.
Q6: What are the common symptoms of an AF 100 communication problem?
Possible symptoms include communication loss, missing status updates, intermittent network faults, or communication-related system alarms. These issues may originate from the interface module, modem, cable, connectors, network configuration, or another connected device. Check the entire communication path before replacing components.
Q7: How can the ABB CI522AK14 communication interface be diagnosed?
Review system diagnostics and communication alarms first. Inspect the module connections, modem, cable, and fieldbus wiring, then verify the network configuration against the system documentation. Replace or test individual components only according to approved maintenance procedures.
Q8: Can the ABB CI522AK14 be replaced with another CI522A interface kit?
Not automatically. Different CI522A kit variants may use different modems, cables, or interface configurations. Before substitution, compare the complete order number, included components, fieldbus requirements, and system compatibility. Confirm an approved replacement with the relevant ABB documentation or technical support.
ABB CI522AK14 3BSE018460R1 AF 100 Communication Interface is in stock. Please contact us for a quick quote and competitive pricing.
