ABB FDNA-01 3ABD68469341 DeviceNet Adapter Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | FDNA-01 |
| Ordering Number | 3ABD68469341 |
| Product Type | DeviceNet Adapter Module |
| Product Series | F-Series Fieldbus Adapter |
| Communication Protocol | DeviceNet |
| Main Function | Connects compatible ABB drives to DeviceNet industrial networks |
| Compatible ABB Drives | ACS355, ACS380, ACS480, ACS580, ACH480, ACH580, ACQ580, ACS880, ACSM1, DCS880, DCT880; verify model-specific compatibility |
| Network Role | DeviceNet Class 2 slave |
| Communication Services | Explicit Messaging, Poll-Response, Change of State and Cyclic |
| Supported Baud Rates | 125, 250, 500 kbit/s |
| Network Supply Voltage | +24 V DC nominal, +11 to +30 V DC |
| Drive-Side Supply Voltage | +3.3 V DC ±5% |
| Drive-Side Current Consumption | 180 mA typical, 300 mA maximum at +3.3 V DC |
| Network-Side Current Consumption | 20 mA typical, 50 mA maximum at +24 V DC |
| Network Topology | Multi-drop |
| Maximum Bus Length | Up to 1,200 m, depending on baud rate and network configuration |
| Bus Termination | External 121 Ω, 1%, 1/4 W metal-film resistor at each end of the trunk line |
| Drive Interface | 20-pin connector |
| Network Connector | Removable 5-pole screw terminal |
| Maximum Terminal Wire Cross-Section | 2.5 mm² |
| Diagnostic Indicators | Three bi-color LEDs: HOST, MODULE and NETWORK |
| Mounting Method | Compatible ABB drive option slot |
| Electrical Isolation | Bus interface functionally isolated from the drive |
| Protection Rating | IP20 |
| EMC Standards | EN 50081-2 and EN 50082-2, as specified in the applicable documentation |
| Estimated Minimum Service Life | 100,000 hours |
| Dimensions | 77 × 27 × 64 mm |
| Weight | 0.049 kg |
FAQ
1. What is the main function of the ABB FDNA-01 DeviceNet Adapter Module?
The ABB FDNA-01 connects compatible ABB drives to a DeviceNet industrial communication network. It allows a PLC or other DeviceNet scanner to send drive commands, exchange speed or torque references, monitor drive status, read actual values, access parameters, and reset certain drive faults through the fieldbus.
2. Which ABB drives are compatible with the FDNA-01?
The FDNA-01 supports selected ABB drive families, including ACS355, ACS380, ACS480, ACS580, ACH480, ACH580, ACQ580, ACS880, ACSM1, DCS880, and DCT880. Compatibility depends on the specific drive model, control hardware, firmware, and available option slot. Check the relevant ABB drive documentation before installation.
3. Which DeviceNet communication speeds does the FDNA-01 support?
The adapter supports 125, 250, and 500 kbit/s. The selected baud rate must match the DeviceNet scanner and other network devices. An inconsistent baud rate can prevent communication even when the module is correctly installed and powered.
4. How should the FDNA-01 be configured before commissioning?
Install the module in a supported drive option slot, connect the DeviceNet cable, and configure the network node address (MAC ID) and baud rate. Enable the fieldbus adapter in the drive parameters, select the required command and reference sources, and refresh the fieldbus parameters where required by the drive firmware. Confirm that the PLC scanner configuration matches the adapter settings.
5. Does the FDNA-01 require external DeviceNet bus termination?
Yes. The adapter does not provide the required bus termination. Install a 121 Ω, 1%, 1/4 W metal-film resistor at each end of the DeviceNet trunk line, connected between CAN_H and CAN_L. Do not install termination resistors at every node, as incorrect termination can cause communication errors.
6. What do the HOST, MODULE, and NETWORK LEDs indicate?
The three bi-color LEDs help identify the operating state of the drive interface, adapter module, and DeviceNet connection. Their colors and flashing patterns indicate different conditions, including normal operation, initialization, communication loss, or faults. Refer to the FDNA-01 user manual for the exact meaning of each LED state.
7. Why does the FDNA-01 fail to communicate with the PLC?
Common causes include a duplicate MAC ID, mismatched baud rates, incorrect wiring, missing or incorrect bus termination, an incompatible EDS file, or an incorrectly configured PLC scanner. Check the CAN_H, CAN_L, shield, V−, and V+ connections, verify network power, inspect the diagnostic LEDs, and confirm that the PLC’s DeviceNet scan list and adapter settings match.
8. How can FDNA-01 communication faults be diagnosed and resolved?
Start by checking the module seating, drive-side power, network supply, and cable connections. Confirm the MAC ID and baud rate, inspect the termination resistors, and review the HOST, MODULE, and NETWORK LED states. If communication is established but drive control does not work, verify the fieldbus enable setting, command source, reference source, and communication-loss response parameters. Consult the applicable ABB drive and FDNA-01 manuals before changing safety-related or operational settings.
ABB FDNA-01 3ABD68469341 DeviceNet Adapter Module is in stock. Please contact us for a quick quote and competitive pricing.
