ABB PSM0004 2RCA025059A0001 Relay Board
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | PSM0004 |
| Ordering Number | 2RCA025059A0001 |
| Product Type | Relay Board / Power Supply Module |
| Product Series | ABB Relion Protection and Control |
| Catalog Description | PSM0004: 100–240 VAC, 48–250 VDC, 6BO |
| Module Designation | PS_H/BO |
| Main Function | Provides auxiliary power supply and binary output functionality in compatible ABB protection and control systems |
| AC Input Voltage | 100–240 V AC |
| DC Input Voltage | 48–250 V DC |
| AC Frequency | 50/60 Hz |
| Binary Outputs | 6 binary outputs |
| Typical DC Power Consumption | Less than 12.5 W |
| Maximum DC Power Consumption | Less than 15 W |
| Typical AC Power Consumption | Less than 13.5 W |
| Maximum AC Power Consumption | Less than 16 W |
| Application | Protection relays, substation automation, and electrical control systems |
| Compatible Equipment | Selected ABB Relion 611 and 615 series protection and control devices; verify compatibility against the specific relay model |
| Product Type Classification | Spare part |
| Installation | Installed within a compatible ABB protection relay assembly |
| Dimensions | 188 × 35 × 150 mm |
| Weight | 0.25 kg |
FAQ
1. What is the main function of the ABB PSM0004 Relay Board?
The ABB PSM0004, ordering number 2RCA025059A0001, is a power supply module with six binary outputs. It provides auxiliary power and output functionality within compatible ABB protection and control equipment, supporting applications such as feeder protection, motor protection, and substation automation.
2. What input voltage does the ABB PSM0004 support?
The module supports an AC input range of 100–240 V and a DC input range of 48–250 V. Before connecting the module, confirm the available auxiliary supply, voltage type, polarity where applicable, and the requirements of the installed protection relay.
3. What does the 6BO designation mean on the PSM0004?
The designation 6BO refers to six binary outputs. These outputs allow the protection system to provide configured digital signals for functions such as alarms, status indication, and control logic. The precise output behavior depends on the relay configuration and application settings.
4. Which ABB protection relays are compatible with the PSM0004?
The PSM0004 is associated with selected ABB Relion protection and control products, including equipment in the 611 and 615 series. Compatibility is model-specific and may depend on the relay hardware configuration. Check the applicable ABB product documentation and spare-parts list before ordering or installing a replacement.
5. What should be checked before installing the PSM0004?
Verify the module’s ordering number, relay compatibility, auxiliary supply voltage, and terminal assignments. Inspect the module and connectors for damage, follow the relay manufacturer’s installation procedure, and isolate the equipment from hazardous voltages before handling internal components.
6. Why might the protection relay fail to start after PSM0004 installation?
Possible causes include an incorrect auxiliary supply voltage, loose connections, incorrect module seating, damaged connectors, or an incompatible module. Check the supply voltage and wiring against the relay documentation. If the power supply is correct but the relay does not start, inspect the diagnostic indications and follow the manufacturer’s troubleshooting procedure.
7. How can binary output faults associated with the PSM0004 be diagnosed?
First, verify that the protection relay is powered and operating normally. Check the configured binary output logic, output assignment, wiring, and connected circuit. Use suitable test equipment to verify the output response under the approved test procedure. If an output does not respond as expected, determine whether the cause lies in the relay configuration, external wiring, connected load, or module itself.
8. Can the PSM0004 be replaced while the protection relay is energized?
Do not assume that the module supports hot replacement. Unless the applicable ABB instructions explicitly permit replacement under energized conditions, isolate the auxiliary supply and follow the approved maintenance procedure. After replacement, verify the relay configuration, output operation, alarm status, and protection functions before returning the equipment to service.
ABB PSM0004 2RCA025059A0001 Relay Board is in stock. Please contact us for a quick quote and competitive pricing.
