ABB FMH2A03TR-EN43CZ Servo Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | FMH2A03TR-EN43CZ |
| Product Name | Servo Drive |
| Product Series | MicroFlex Analog |
| Drive Type | Analog Servo Drive |
| Input Voltage | 105–250 V AC |
| Input Phase | Single-phase or three-phase |
| DC Bus Voltage | 160–320 V DC |
| Continuous Output Current | 3 A RMS |
| Peak Output Current | 6 A RMS |
| Feedback Type | Incremental Encoder Feedback |
| Communication Interface | RS422 |
| External Control Supply | +24 V DC required for I/O operation |
| Control Function | Servo motor speed, torque, and position control |
| Regenerative Resistor | External regenerative resistor required where specified by the application |
| Cooling | Natural convection; verify ventilation requirements for the installation |
| Typical Applications | Industrial machinery, automated production equipment, positioning systems, and motion control |
| Dimensions | 180 × 80 × 157 mm |
| Weight | 1.45 kg |
FAQ
Q1: What is the main function of the ABB FMH2A03TR-EN43CZ servo drive?
A1: The FMH2A03TR-EN43CZ is an analog servo drive designed to control compatible servo motors in industrial motion-control systems. It regulates motor operation using command signals and encoder feedback, supporting controlled speed, torque, and positioning.
Q2: What input voltage does the FMH2A03TR-EN43CZ support?
A2: The drive supports an AC input range of 105–250 V and can be configured for single-phase or three-phase input, subject to the manufacturer’s wiring and installation requirements. The supply configuration must be checked before commissioning.
Q3: What are the continuous and peak output current ratings?
A3: The drive has a continuous output current rating of 3 A RMS and a peak output current rating of 6 A RMS. The peak rating is intended for short-duration demands within the specified operating limits. The selected motor must be compatible with the drive’s current and voltage ratings.
Q4: What type of feedback does this servo drive use?
A4: The EN43 configuration uses incremental encoder feedback with an RS422 interface. The encoder provides motor position and speed information for closed-loop control. Encoder signal format, wiring, and electrical compatibility should be verified before connecting the motor.
Q5: Why does the drive require an external +24 V DC supply?
A5: An external +24 V DC supply is required for the drive’s I/O operation. It powers the relevant control interface circuits and allows the drive to receive or exchange control signals with compatible automation equipment. Follow the wiring diagram for supply polarity and terminal assignments.
Q6: Can the FMH2A03TR-EN43CZ operate with any servo motor?
A6: No. The motor must be compatible with the drive’s output voltage, continuous and peak current ratings, feedback type, encoder interface, and control requirements. Check the motor nameplate and the drive documentation before selecting or replacing a motor.
Q7: What should be checked if the servo motor does not start?
A7: Check the AC input supply, external +24 V DC supply, drive-ready status, enable signal, fault indicators, motor wiring, and encoder connections. Confirm that the control command is valid and that no safety interlock or alarm is preventing operation. Disconnect power before inspecting electrical connections.
Q8: What should be considered when replacing an existing FMH2A03TR-EN43CZ?
A8: Confirm the complete model number and hardware configuration. Verify the AC input supply, motor current requirements, encoder and RS422 wiring, I/O supply, control signal configuration, and regenerative resistor requirements. After installation, configure the drive according to the application and perform controlled commissioning tests before returning the machinery to normal operation.
