Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model Number | PFCL 201CE |
| Ordering Number | 3BSX802939-108 |
| Product Name | Pillow-Type Load Cell |
| Product Series | Pressductor PFCL 201 |
| Product Type | Vertical Force Load Cell |
| Measurement Principle | Pressductor magnetoelastic technology |
| Rated Load | 50 kN |
| Extended Load | 75 kN at ±1% accuracy class |
| Accuracy Class | ±0.5% |
| Linearity Deviation | Less than ±0.3% |
| Repeatability Error | Less than ±0.05% |
| Hysteresis | Less than 0.2% |
| Measuring Direction | Vertical |
| Material | Stainless steel |
| Working Temperature Range | -10 to +90°C |
| Cable Connection | Fixed cable with protective hose |
| Typical Applications | Rolling mills, strip tension measurement, and continuous metal-processing lines |
| Dimensions | 450 × 110 × 124.6 mm |
| Weight | 10 kg |
FAQ
1. What is the main function of the ABB PFCL 201CE Load Cell?
The ABB PFCL 201CE is designed to measure vertical force in industrial rolling and strip-processing systems. Its output signal allows compatible measurement electronics to monitor load and calculate strip tension, supporting stable operation and process control.
2. How does the Pressductor measurement principle work?
The sensor uses the magnetoelastic effect. Mechanical stress changes the magnetic properties of the sensing element, producing an electrical signal related to the applied force. This technology supports force measurement without relying on significant mechanical displacement.
3. What does the 50 kN rated load mean?
The 50 kN rating represents the nominal force the load cell is designed to measure in its specified measurement direction. The operating load should remain within ABB’s published limits, and any extended-load operation must follow the specified accuracy and installation requirements.
4. Which applications commonly use the PFCL 201CE?
Typical applications include steel rolling mills, strip tension monitoring, and continuous metal-processing lines such as annealing, pickling, and galvanizing systems. It is suitable for installations that require dependable force measurement during production.
5. What should be checked before installing the load cell?
Verify the model and ordering number, rated load, mounting surfaces, force direction, fasteners, and cable routing. The load cell must be correctly aligned so that the intended force is measured without unwanted mechanical forces affecting the reading.
6. What can cause unstable or inaccurate measurement signals?
Possible causes include loose mounting hardware, incorrect alignment, excessive vibration, damaged cables, electrical interference, or problems with the connected measurement electronics. Inspect the mechanical installation and electrical signal path before replacing the sensor.
7. How should the PFCL 201CE cable be installed?
The fixed cable and protective hose should be routed according to ABB’s installation instructions. Avoid sharp bends, pulling forces, crushing, and bending close to the connection area. Improper cable routing can damage the connection or cause intermittent measurement signals.
8. What should be verified when replacing an existing PFCL 201CE?
Confirm the complete model and ordering number, rated load, measurement direction, cable configuration, and compatibility with the existing ABB measurement electronics. The replacement must match the original system requirements; a similar appearance alone does not guarantee compatibility.
ABB PFCL 201CE 3BSX802939-108 Load Cell is in stock. Please contact us for a quick quote and competitive pricing.
