ABB TB850 3BSC950193R1 CEX Bus Terminator
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | CEX Bus Terminator |
| Model | TB850 |
| Order Number | 3BSC950193R1 |
| Manufacturer | ABB |
| Product Type | CEX Bus Terminator |
| Function | CEX bus termination and impedance matching |
| Application | CEX bus end termination in industrial automation systems |
| Compatible Systems | ABB AC 800M / 800xA systems |
| Electrical Function | Signal reflection suppression and impedance matching |
| Communication Type | CEX expansion bus |
| Installation Type | DIN rail mounting |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| EMC Protection | Industrial-grade electromagnetic compatibility design |
| Dimensions | 55 × 16 × 50 mm |
| Weight | 0.04 kg |
FAQ
1. What is the main function of the TB850 CEX bus terminator?
The TB850 is used to provide proper termination for the ABB CEX expansion bus. Its main function is impedance matching at the end of the communication line, which prevents signal reflections and ensures stable and reliable data transmission.
2. Why is termination required on the CEX bus?
Without proper termination, high-speed communication signals can reflect back from the end of the bus line, causing data corruption, communication errors, or system instability. The TB850 eliminates these reflections by providing correct electrical termination.
3. Where should the TB850 be installed in the system?
The TB850 must be installed at the physical end of the CEX bus segment. Correct placement is essential to ensure signal integrity and stable communication across the entire system.
4. Does the TB850 affect system performance or communication speed?
The TB850 does not process data and does not reduce communication speed. Its role is to improve signal quality, which helps maintain stable and error-free communication performance.
5. Does the TB850 require configuration or programming?
No, the TB850 is a passive hardware component. It requires no software configuration or programming and becomes active immediately after correct installation.
6. What happens if the TB850 is not installed?
Without proper termination, the CEX bus may experience signal reflections, increased communication errors, intermittent data loss, or even system instability in severe cases.
7. Can the TB850 be used in redundant system architectures?
Yes, in redundant systems each independent CEX bus segment still requires proper termination. The TB850 ensures stable operation by terminating each communication line correctly.
8. How does the TB850 improve overall system reliability?
By eliminating signal reflections and ensuring correct impedance matching, the TB850 reduces communication disturbances and data errors, leading to more stable operation and improved reliability in industrial automation systems.
ABB TB850 3BSC950193R1 CEX Bus Terminator is in stock. Please contact us for a quick quote and competitive pricing.
