ABB ZINT-792+N8205 3AXD50000030405 MC Interface Board
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Model | ZINT-792 +N8205 |
| Order Number | 3AXD50000030405 |
| Product Type | MC Interface Board |
| Product Name | ZINT-792 +N8205 WITH RATING SP |
| Drive Family | ABB ACS880 |
| Typical Application | ACS880-01 frequency converter spare-part applications |
| Main Function | Provides the main interface between the control unit and the drive power/control circuitry |
| Compatible Control Unit | ZCU control unit |
| Board Configuration | With Rating SP |
| Programming Status | Pre-loaded with the applicable PU type and Rating ID |
| Service Application | Replacement MC interface board for applicable ACS880 configurations |
| Firmware Compatibility | Compatible with applicable ACS880 drive firmware configurations; ZINT-792 variants are associated with firmware 2.30 or later |
| Interface Function | Handles control, monitoring, communication and interface signals between the ZCU control unit and the drive |
| Installation Position | Installed as the MC interface board within the applicable ACS880 drive module |
| Typical Drive Frame | Applicable ACS880-01 configurations, including R6–R9 depending on drive type and rating |
| Supply / Signal Interface | Interfaces with the drive’s internal low-voltage control and signal circuits |
| Programming | Rating information is pre-loaded for the specified spare-part configuration |
| Material | Industrial-grade printed circuit board assembly |
| Country of Origin | Sweden |
| Customs Tariff Code | 85049099 |
| Dimensions | 235 × 145 × 30 mm |
| Weight | 0.4 kg |
FAQ
1. What is the ABB ZINT-792 +N8205 3AXD50000030405?
It is an ABB MC Interface Board used in applicable ACS880 drive systems. The board provides the interface between the ZCU control unit and the drive’s internal control and monitoring circuits.
2. What is the difference between ZINT-792 +N8205 and the order number 3AXD50000030405?
ZINT-792 +N8205 is the board designation, while 3AXD50000030405 is the ABB order number identifying the specific spare-part version with the required rating information.
3. What does “WITH RATING SP” mean for this board?
It indicates that the spare-part board is supplied with the applicable drive rating information already loaded. This reduces the need for the rating information to be programmed separately during replacement.
4. Which ABB drive family uses the ZINT-792 +N8205 board?
The board is associated with the ABB ACS880 drive family, particularly applicable ACS880-01 configurations. Exact compatibility depends on the drive type, frame size, control unit and rating information.
5. Is the ZINT-792 +N8205 compatible with a ZCU control unit?
Yes. ZINT-792 is designed for use with ZCU-based ACS880 control architectures. The exact ZCU variant and drive configuration should be checked before installing a replacement board.
6. Does the board require programming after installation?
The 3AXD50000030405 version is a pre-loaded “WITH RATING SP” spare-part board. Therefore, the required rating information is supplied with the board. However, drive-specific commissioning and parameter verification may still be required after replacement.
7. What should be checked before replacing a ZINT-792 +N8205 board?
Verify the complete order number 3AXD50000030405, the existing drive type and frame size, ZCU control unit version, rating information, firmware compatibility and connector arrangement. The original board’s configuration should also be documented before removal.
8. What symptoms may indicate a faulty ZINT-792 +N8205 MC Interface Board?
Possible symptoms include communication problems between the control unit and drive, incorrect drive identification or rating information, abnormal control signals, startup failures, diagnostic faults, or loss of internal interface functions. Before replacing the board, power supply, connectors, control unit, firmware and related wiring should also be checked.
ABB ZINT-792+N8205 3AXD50000030405 MC Interface Board is in stock. Please contact us for a quick quote and competitive pricing.
