1756-OF8IHK Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 1756-OF8IHK ControlLogix Isolated Analog Output Module |
| Brand | Allen Bradley |
| Product Type | Industrial Equipment |
| Series | ControlLogix |
| Module Type | Isolated Analog Output Module |
| Number of Outputs | 8 |
| Output Type | Current Output |
| Output Range | 0–20 mA, 4–20 mA |
| Resolution | 16-bit |
| Converter Resolution | 16-bit Digital-to-Analog (D/A) |
| Accuracy | ±0.1% Full Scale |
| Channel Isolation | Individually Isolated Channels |
| Backplane Isolation | 250V Continuous |
| Output Load Range | 0–750 Ω |
| Update Time | Approx. 2 ms |
| Open Circuit Detection | Yes |
| Calibration | Factory Calibrated |
| Power Supply | Supplied from ControlLogix Backplane |
| Current Draw @ 5.1V DC | Approx. 250 mA |
| Current Draw @ 24V DC | Approx. 160 mA |
| Power Dissipation | Approx. 5.5 W |
| Thermal Dissipation | Approx. 18.8 BTU/hr |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5%–95% Non-Condensing |
| Mounting Type | ControlLogix Chassis Mount |
| Certifications | UL, CE, CSA, FM, ATEX, IECEx, RoHS |
| Lifecycle Status | Active |
| Dimensions (H × W × D) | Approx. 145 × 38 × 140 mm |
| Weight | Approx. 0.32 kg |
| Typical Applications | Process control systems, chemical plants, oil and gas facilities, power generation, water treatment, industrial automation, analog actuator control |
FAQ
What is the 1756-OF8IHK used for?
It is an 8-channel isolated analog output module used to send analog current control signals from a ControlLogix controller to field devices such as valves, actuators, and process control equipment.
What output signals does the module support?
The module supports 0–20 mA and 4–20 mA analog current outputs.
Are the output channels isolated?
Yes, each output channel is individually isolated, helping reduce electrical noise and improve signal integrity.
What is the resolution of the analog outputs?
The module provides 16-bit output resolution for precise analog control.
Can the module detect open output circuits?
Yes, it includes open-circuit detection diagnostics for improved system monitoring.
What industries commonly use this module?
It is widely used in process automation, chemical processing, oil and gas, water treatment, power generation, and manufacturing control systems.
Allen Bradley 1756-OF8IHK Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
