2080-IF4 Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 2080-IF4 Micro800 4-Point Analog Input Plug-In Module |
| Brand | Allen Bradley |
| Product Type | Industrial Equipment |
| Series | Micro800 |
| Module Type | Analog Input Plug-In Module |
| Number of Analog Inputs | 4 |
| Input Type | Voltage / Current Analog Input |
| Voltage Input Range | 0–10V DC |
| Current Input Range | 0–20 mA |
| Input Configuration | Software Configurable per Channel |
| Resolution | 12-bit |
| Data Range | 0–65535 |
| Accuracy | ±1% Full Scale @ 25°C |
| Repeatability | ±0.1% |
| Non-Linearity | ±0.1% Full Scale |
| Update Time | 180 ms per Enabled Channel |
| Channel Isolation | Non-Isolated |
| Input Group to Bus Isolation | None |
| Input Impedance | >100 kΩ (Voltage Mode), 250 Ω (Current Mode) |
| Power Consumption | <60 mA @ 3.3V |
| Electrical Connection | Screw Connection |
| Recommended Shielded Cable Length | 10 m Maximum |
| Mounting Type | Plug-In Module for Micro800 Controllers |
| Compatible Controllers | Micro820, Micro830, Micro850 |
| Operating Temperature | -20°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5%–95% Non-Condensing |
| Operating Altitude | Up to 2000 m |
| Certifications | UL, CE, CSA, RoHS |
| Lifecycle Status | Active |
| UPC | 885630058399 |
| Country of Origin | Singapore |
| Dimensions (L × W × H) | Approx. 87 × 40 × 90 mm |
| Weight | Approx. 0.23 kg |
| Typical Applications | Process monitoring, analog sensor integration, pressure transmitters, flow sensors, level measurement systems, industrial automation control |
FAQ
What is the 2080-IF4 used for?
It is a 4-channel analog input plug-in module used to add voltage and current analog inputs to Micro800 controllers.
Which controllers are compatible with this module?
It is compatible with Allen Bradley Micro820, Micro830, and Micro850 controllers.
What input signals does the module support?
The module supports 0–10V DC voltage inputs and 0–20 mA current inputs.
Is channel isolation provided?
No, the 2080-IF4 is a non-isolated analog input module.
What is the analog input resolution?
The module provides 12-bit analog input resolution with a data range of 0–65535.
What industries commonly use this product?
It is widely used in manufacturing, water treatment, process control, HVAC systems, material handling equipment, and general industrial automation applications.
