Allen Bradley 20BP292N0NNNNNC0 PowerFlex 700 AC Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen Bradley |
| Model | 20BP292N0NNNNNC0 |
| Series | PowerFlex 700 |
| Product Type | AC Drive |
| Input Voltage | 540 VDC |
| Input Type | DC Input with Precharge |
| Rated Output Current | 292 A |
| Normal-Duty Power Rating | 160 kW |
| Heavy-Duty Power Rating | 150 kW |
| Frame Size | Frame 7 |
| Mounting Configuration | Open / Flange Mount |
| Enclosure Rating | IP00 |
| Control Method | Vector Control |
| Control I/O | 24 VDC I/O |
| Feedback | No Feedback |
| Communication Interface | RS485 |
| Internal Communication Module | None |
| Human Interface | HIM Blank Cover |
| Brake IGBT | None |
| Internal Brake Resistor | None |
| PWM Frequency | 4 kHz |
| Input Phase | DC Input |
| Output Phase | Three-phase |
| Continuous Output Current | 292 A |
| 1-Minute Output Current | 322 A |
| 3-Second Output Current | 438 A |
| DC Input Current | 342 A |
| Maximum Output Frequency | 420 Hz |
| Cooling Method | Forced-Air Cooling |
| Precharge | Yes |
| Dimensions | 1498.6 × 409.3 × 509.3 mm |
| Weight | 147 kg |
FAQ
1. What is the rated output current of the Allen Bradley 20BP292N0NNNNNC0?
The 20BP292N0NNNNNC0 has a continuous rated output current of 292 A. Its output current can reach 322 A for 1 minute and 438 A for 3 seconds under the specified operating conditions.
2. What type of input power does the 20BP292N0NNNNNC0 require?
This model uses a 540 VDC input with a precharge circuit. The DC supply voltage and input protection should be verified before the drive is energized.
3. What is the power rating of the 20BP292N0NNNNNC0?
The drive is rated at 160 kW for normal-duty operation. The applicable heavy-duty rating is 150 kW. The correct rating should be selected according to the motor load profile and operating conditions.
4. Does the 20BP292N0NNNNNC0 support encoder feedback?
No. The N0 configuration is supplied without a feedback option. Applications requiring closed-loop encoder control should use a compatible PowerFlex 700 configuration with the required feedback interface.
5. What communication interface is available on the 20BP292N0NNNNNC0?
The model provides an RS485 communication interface and does not include an internal communication module. The communication parameters should be configured according to the connected control system.
6. Does the 20BP292N0NNNNNC0 include a braking IGBT or internal braking resistor?
No. This configuration does not include a Brake IGBT or an internal braking resistor. If the application requires rapid deceleration or dissipating regenerative energy, an external braking solution should be evaluated.
7. What type of control I/O does the 20BP292N0NNNNNC0 provide?
The drive provides 24 VDC control I/O for connection to compatible control circuits. The I/O configuration should be checked against the PLC, DCS, or other automation equipment used in the system.
8. What should be checked before commissioning the 20BP292N0NNNNNC0?
Verify the 540 VDC supply, DC polarity, precharge circuit, motor ratings, power wiring, grounding, ventilation, control I/O, RS485 communication settings, and motor-control parameters. Because this is an open/flange-mount Frame 7 drive, the cabinet and cooling arrangement should also provide appropriate environmental and thermal protection.
Allen Bradley 20BP292N0NNNNNC0 PowerFlex 700 AC Drive is in stock. Please contact us for a quick quote and competitive pricing.
