Allen Bradley 20F11ND5P0JA0NNNNN PowerFlex 753 AC Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 20F11ND5P0JA0NNNNN |
| Product Type | AC Drive |
| Series | PowerFlex 753 |
| Brand | Allen-Bradley |
| Drive Type | Air-Cooled AC Drive |
| Input Voltage | 380–480 VAC, 3-Phase |
| DC Bus Voltage | 650 VDC |
| Output Current | 5 A |
| Normal-Duty Power | 3 HP / 2.2 kW |
| Heavy-Duty Power | 2 HP / 1.5 kW |
| Frame Size | Frame 2 |
| Input Type | AC Input with Precharge and DC Terminals |
| Enclosure Type | IP20/IP00, NEMA/UL Open Type |
| Cooling Method | Forced Air |
| Embedded I/O | Included |
| EMC Filtering | Filtered |
| Common Mode Capacitor | Jumper Installed |
| Dynamic Braking | Internal DB Transistor |
| HMI | Blank Cover, No HIM |
| Control Method | V/Hz, Sensorless Vector, Flux Vector with Optional Feedback |
| Operating Temperature | 0 to 50°C |
| Humidity | 5–95% RH, Non-Condensing |
| Application | Industrial Motor Speed and Torque Control |
| Dimensions | 424.2 × 134.5 × 212 mm |
| Weight | 7.8 kg |
FAQ
1. What is the output current of the Allen-Bradley 20F11ND5P0JA0NNNNN?
The PowerFlex 753 20F11ND5P0JA0NNNNN has a continuous output current rating of 5 A. This rating supports motors up to 3 HP under normal-duty operation and 2 HP under heavy-duty operation, depending on the actual motor load and operating conditions.
2. What input voltage does the 20F11ND5P0JA0NNNNN require?
The drive accepts a 380–480 VAC, three-phase input supply. It uses an AC input configuration with precharge and DC terminals. Before energizing the drive, verify the incoming voltage, phase configuration, grounding, protective devices, and power wiring.
3. What motor power can the 20F11ND5P0JA0NNNNN support?
The drive is rated for 3 HP (2.2 kW) under normal-duty conditions and 2 HP (1.5 kW) under heavy-duty conditions. Motor selection should also consider rated current, starting torque, overload requirements, acceleration and deceleration demands, and the application’s duty cycle.
4. Does the 20F11ND5P0JA0NNNNN include dynamic braking?
Yes. The drive includes an internal dynamic braking transistor. When used with an appropriately sized external braking resistor, it can dissipate regenerated energy during deceleration and help control DC bus voltage during rapid or frequent stopping.
5. What cooling method does the PowerFlex 753 20F11ND5P0JA0NNNNN use?
The drive uses forced-air cooling. Internal airflow removes heat generated by the power components during operation. Adequate ventilation and unobstructed airflow should be maintained, particularly when the drive is installed inside an electrical cabinet or operates continuously under load.
6. What control methods are available for this PowerFlex 753 drive?
The 20F11ND5P0JA0NNNNN supports V/Hz control and sensorless vector control, with flux vector control available when the appropriate feedback configuration is used. The control method should be selected according to the required speed regulation, torque performance, and application characteristics.
7. What should be checked when commissioning the 20F11ND5P0JA0NNNNN?
Commissioning should include verification of the incoming voltage, motor nameplate data, rated current, frequency, acceleration and deceleration times, current limits, motor protection settings, control mode, and start/stop configuration. A low-speed test should be performed first to confirm motor rotation and drive response.
8. What can cause overcurrent or DC bus faults on the 20F11ND5P0JA0NNNNN?
Overcurrent faults can result from excessive mechanical load, incorrect motor parameters, motor wiring problems, short circuits, or insufficient acceleration time. DC bus overvoltage can occur during rapid deceleration or regenerative operation. Troubleshooting should include checking motor connections, load conditions, ramp settings, motor parameters, and the braking circuit.
Allen Bradley 20F11ND5P0JA0NNNNN PowerFlex 753 AC Drive is in stock. Please contact us for a quick quote and competitive pricing.
