Allen Bradley 20F1ANC170AN0NNNNN PowerFlex 753 AC Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | 20F1ANC170AN0NNNNN |
| Product Series | PowerFlex 753 |
| Product Type | AC Drive |
| Input Voltage | 400 V AC |
| Input Phase | Three-phase |
| Rated Output Current | 170 A |
| Normal-Duty Power Rating | 90 kW |
| Heavy-Duty Power Rating | 75 kW |
| Input Type | AC input with precharge, no DC terminals |
| Frame Size | Frame 6 |
| Cooling Method | Air cooled |
| Enclosure Rating | IP20/IP00 |
| Enclosure Type | Open Type |
| EMC Filtering | EMC filter |
| Common-Mode Capacitor | Jumper removed |
| Dynamic Braking | None |
| Embedded I/O | Supported |
| HIM | Blank, no HIM |
| Motor Control | V/Hz, Sensorless Vector, Vector Control |
| PID Control | Supported |
| Communication | Expandable through PowerFlex 753 communication option modules |
| Typical Applications | Conveyors, pumps, fans, compressors, material handling and industrial machinery |
| Dimensions | 665.5 × 308 × 346.4 mm |
| Weight | 38.6 kg |
FAQ
1. What is the rated output current of the 20F1ANC170AN0NNNNN?
The PowerFlex 753 20F1ANC170AN0NNNNN has a rated output current of 170 A. Motor selection should be based on the motor nameplate current and the required duty rating, rather than power rating alone.
2. What are the normal-duty and heavy-duty ratings of this drive?
The drive provides a 90 kW normal-duty rating and a 75 kW heavy-duty rating. The appropriate rating depends on the motor load profile, starting torque, overload requirements, and acceleration characteristics.
3. What type of input power does the 20F1ANC170AN0NNNNN require?
It uses a three-phase 400 V AC input with precharge. This configuration has no DC input terminals. The incoming power supply should be properly protected and sized for the drive and installation conditions.
4. Does this model include an internal dynamic braking transistor?
No. The 20F1ANC170AN0NNNNN does not include an internal dynamic braking transistor. If the application requires rapid deceleration or controlled dissipation of regenerative energy, an appropriate external braking solution should be evaluated.
5. What is the purpose of the EMC filter and common-mode capacitor configuration?
The drive is equipped with EMC filtering, while the common-mode capacitor jumper is removed in this configuration. This arrangement affects conducted electromagnetic noise and grounding behavior, so the configuration should be matched to the site’s power distribution and grounding system.
6. Can the 20F1ANC170AN0NNNNN be controlled by a PLC or DCS?
Yes. The PowerFlex 753 platform can be integrated with PLC or DCS systems through compatible communication option modules. Control commands, speed references, drive status, alarms, and diagnostic information can be exchanged with the control system.
7. What should be checked if an overcurrent fault occurs?
Check the motor and output cables for short circuits, grounding faults, and incorrect connections. Verify the motor nameplate parameters, acceleration time, and control settings. The mechanical load should also be inspected for excessive resistance, blockage, or sudden load changes.
8. What should be verified before commissioning the 20F1ANC170AN0NNNNN?
Verify the three-phase input supply, motor wiring, grounding, motor nameplate data, control wiring, I/O configuration, and drive parameters. Perform a controlled initial test at low speed and confirm motor direction, operating current, acceleration response, and fault status before applying the full load.
Allen Bradley 20F1ANC170AN0NNNNN PowerFlex 753 AC Drive is in stock. Please contact us for a quick quote and competitive pricing.
