Allen-Bradley 20G11LF590AN2NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley / Rockwell Automation |
| Product Type | PowerFlex 755 AC Drive |
| Catalog Number | 20G11LF590AN2NNNNN |
| Input Voltage | 690 VAC |
| Input Phase | 3 Phase |
| Rated Current | 590 A |
| Low-Duty Power Rating | 630 kW |
| Normal-Duty Power Rating | 560 kW |
| Heavy-Duty Power Rating | 450 kW |
| Frame Size | Frame 9 |
| Cooling Method | Air Cooled / Forced Air |
| Communication | Embedded EtherNet/IP |
| Input Configuration | AC Input with DC Terminals |
| Enclosure | Type 1, IP20 |
| Cabinet Style | 800 mm Deep MCC Style |
| EMC Filtering | Filtered |
| CM Jumper | Removed |
| Dynamic Braking | None |
| HIM | Enhanced LCD, Full Numeric HIM |
| Dimensions | 800 mm deep MCC-style configuration; overall height and width depend on the packaged arrangement |
| Weight | 10kg |
The 20G11LF590AN2NNNNN is an Allen-Bradley PowerFlex 755 AC drive for high-power three-phase motor applications. The LF590 configuration is rated at 590 A for 690 VAC service, with 630 kW low-duty, 560 kW normal-duty, and 450 kW heavy-duty ratings. Rockwell Automation identifies the LF590 family as a Frame 9, 800 mm deep MCC-style PowerFlex 755 configuration with embedded EtherNet/IP, filtered input, and forced-air cooling.
The AN2 configuration uses the CM jumper removed and includes an Enhanced LCD Full Numeric HIM. The PowerFlex 755 catalog family supports different HIM and CM-jumper configurations, while the corresponding AN0 version uses the same drive ratings with a blank/no-HIM arrangement.
FAQ
Q1: What is the Allen-Bradley 20G11LF590AN2NNNNN?
A: It is a PowerFlex 755 AC drive designed for high-power industrial motor-control applications. This model uses a Frame 9 configuration and includes an Enhanced LCD Full Numeric HIM.
Q2: What input voltage does the 20G11LF590AN2NNNNN use?
A: The drive is designed for a 690 VAC, three-phase input supply and has a rated current of 590 A. The LF series covers high-power 690 VAC PowerFlex 755 applications.
Q3: What are the power ratings of this drive?
A: The published ratings for the 590 A configuration are 630 kW for low-duty operation, 560 kW for normal-duty operation, and 450 kW for heavy-duty operation.
Q4: Does the 20G11LF590AN2NNNNN include embedded EtherNet/IP?
A: Yes. Embedded EtherNet/IP is part of the PowerFlex 755 configuration, allowing the drive to communicate with compatible industrial automation and control systems.
Q5: What type of cooling does this PowerFlex 755 use?
A: The drive uses forced-air cooling. Rockwell’s LF590 family data identifies a forced-air configuration with a backward-curved centrifugal fan.
Q6: What does the AN2 configuration indicate?
A: The AN2 configuration uses the CM jumper removed and includes an Enhanced LCD Full Numeric HIM. This distinguishes it from the AN0 version, which uses the same basic drive configuration with a blank/no-HIM arrangement.
Q7: What enclosure configuration is used on the 20G11LF590AN2NNNNN?
A: The drive uses a Type 1, IP20 enclosure in an 800 mm deep MCC-style configuration. It is an air-cooled Frame 9 PowerFlex 755 packaged drive.
Q8: What are the dimensions and weight of the 20G11LF590AN2NNNNN?
A: The packaged configuration is 800 mm deep in the MCC-style arrangement. Exact overall height, width, and final weight depend on the packaged installation, so the applicable Frame 9 mechanical drawing should be used for precise installation and shipping information. Rockwell provides standard dimension drawings and 3D models through its product documentation.
Allen-Bradley 20G11LF590AN2NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
