Allen-Bradley 20G11LF590JN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Product Type | PowerFlex 755 AC Drive |
| Catalog Number | 20G11LF590JN0NNNNN |
| Input Voltage | 690 VAC |
| Input Phase | 3 Phase |
| Rated Current | 590 A |
| Low-Duty Power Rating | 630 kW |
| Normal-Duty Power Rating | 560 kW |
| Heavy-Duty Power Rating | 450 kW |
| Frame Size | Frame 9 |
| Cooling Method | Forced Air |
| Communication | Embedded EtherNet/IP |
| Input Configuration | AC Input with Precharge and DC Terminals |
| Enclosure | Type 1, IP20 |
| Cabinet Style | 800 mm Deep MCC Style |
| EMC Filtering | Filtered |
| CM Jumper | Installed |
| Dynamic Braking | None |
| HIM | Blank / No HIM |
| Dimensions | 800 mm deep MCC-style configuration; overall height and width depend on the packaged arrangement |
| Weight | 10kg |
The 20G11LF590JN0NNNNN is an Allen-Bradley PowerFlex 755 air-cooled packaged AC drive rated for 690 VAC three-phase applications. Rockwell Automation specifies a 590 A output rating, with 630 kW low-duty, 560 kW normal-duty, and 450 kW heavy-duty ratings. The unit uses Frame 9 construction, forced-air cooling, embedded EtherNet/IP, filtered input circuitry, and an 800 mm deep MCC-style package.
The JN0 configuration has the CM jumper installed and is supplied with a blank/no-HIM arrangement. Rockwell also identifies the input as AC with precharge and DC terminals, with Type 1/IP20 protection and no internal dynamic-braking option.
FAQ
Q1: What is the Allen-Bradley 20G11LF590JN0NNNNN?
A: It is a PowerFlex 755 air-cooled AC drive designed for high-power three-phase industrial motor-control applications. It belongs to the Frame 9, 690 VAC range.
Q2: What is the rated current of the 20G11LF590JN0NNNNN?
A: The drive has a rated output current of 590 A. Rockwell Automation lists this model with 630 kW low-duty, 560 kW normal-duty, and 450 kW heavy-duty ratings.
Q3: What input voltage does this PowerFlex 755 drive use?
A: The 20G11LF590JN0NNNNN is designed for a 690 VAC, three-phase input. Its configuration includes AC input with precharge and DC terminals.
Q4: Does the 20G11LF590JN0NNNNN support EtherNet/IP?
A: Yes. Embedded EtherNet/IP is included, allowing the drive to connect with compatible PLCs, controllers, and other industrial automation equipment.
Q5: What type of cooling does this drive use?
A: The drive uses forced-air cooling. Rockwell’s product description identifies it as a PowerFlex 755 air-cooled drive, with the packaged unit using a forced-air arrangement.
Q6: What does the JN0 configuration include?
A: The JN0 configuration includes an installed CM jumper and a blank/no-HIM arrangement. It also uses filtered input circuitry and does not include an internal dynamic-braking option.
Q7: What enclosure and cabinet configuration does this model use?
A: The drive is specified with Type 1, IP20 protection and an 800 mm deep MCC-style package. The packaged construction is intended for larger industrial drive installations.
Q8: What are the dimensions and weight of the 20G11LF590JN0NNNNN?
A: The catalog configuration is an 800 mm deep MCC-style Frame 9 package. Overall height, width, and final packaged weight can vary with the equipment arrangement, so the applicable Rockwell mechanical drawing should be used for installation planning. Rockwell provides standard dimension drawings and 3D model documentation for this catalog number.
