Allen Bradley 80026-044-06-R PROFIBUS DPV1 Master Communication Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | ILX69-PBM |
| Product Type | PROFIBUS DPV1 Master Communication Module |
| Product Series | ProSoft Technology ILX69 Series |
| Main Function | Communication module for integrating PROFIBUS devices with Rockwell CompactLogix control systems |
| Compatible Platform | Rockwell Automation CompactLogix 1769 platform |
| Communication Protocol | PROFIBUS DP / DPV1 |
| Communication Role | PROFIBUS Master |
| Maximum Number of Slaves | Up to 125 PROFIBUS slave devices |
| PROFIBUS Interface | Isolated RS-485 interface |
| PROFIBUS Connector | 9-pin D-Sub female connector |
| PROFIBUS Data Rate | 9.6 kbit/s to 12 Mbit/s |
| Maximum Cyclic Input Data | 5712 bytes |
| Maximum Cyclic Output Data | 5760 bytes |
| Maximum Input Data per Slave | 244 bytes |
| Maximum Output Data per Slave | 244 bytes |
| Acyclic Communication | Supports PROFIBUS DPV1 Class 1 and Class 2 communication |
| Host Interface | 1769 backplane interface |
| Processor | netX 100 communication processor |
| Memory | 8 MB SDRAM, 16 MB Flash memory |
| Ethernet Interface | 10/100 Mbps Ethernet diagnostic port |
| Ethernet Connector | RJ45 |
| Configuration Method | PC-based configuration software |
| Memory Card Support | SD / SDHC card support |
| Power Supply | 5 VDC supplied through CompactLogix backplane |
| Current Consumption | Approximately 570 mA at 5 VDC |
| Isolation Voltage | 500 VDC isolation from backplane |
| LED Indicators | SYS, COM, DIAG, Ethernet Link/Activity indicators |
| Mounting Method | CompactLogix chassis mounting |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 131.6 × 92.1 × 39.3 mm (L × W × H) |
| Weight | Approximately 152 g |
| Application Areas | Industrial communication networks, PLC systems, process automation, machine control, and PROFIBUS device integration |
FAQ
Q1: What is the main function of the ILX69-PBM?
A1: The ILX69-PBM is a PROFIBUS DPV1 Master communication module used to connect CompactLogix controllers with PROFIBUS field devices for industrial data exchange.
Q2: Which PLC platforms are compatible with the ILX69-PBM?
A2: The module is designed for Rockwell Automation CompactLogix 1769 controller platforms and communicates through the 1769 backplane.
Q3: How many PROFIBUS devices can the ILX69-PBM support?
A3: The module can communicate with up to 125 PROFIBUS slave devices on a single network.
Q4: What communication speed does the ILX69-PBM support?
A4: The module supports PROFIBUS communication speeds from 9.6 kbit/s up to 12 Mbit/s depending on network requirements.
Q5: Does the ILX69-PBM support DPV1 functions?
A5: Yes. The module supports PROFIBUS DPV1 acyclic communication, allowing advanced parameter access and device diagnostics.
Q6: How is the ILX69-PBM configured?
A6: The module is configured through dedicated configuration software, allowing users to set PROFIBUS parameters, slave data mapping, and communication settings.
Q7: What applications are suitable for the ILX69-PBM?
A7: Typical applications include factory automation, process control, machine integration, and industrial systems requiring PROFIBUS communication with CompactLogix controllers.
Q8: How can users troubleshoot communication issues with the ILX69-PBM?
A8: Troubleshooting should include checking PROFIBUS cable connections, slave addresses, baud rate settings, termination resistors, module LED status, and controller configuration.
