MVI69E-MBTCP Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | MVI69E-MBTCP Modbus TCP/IP Communication Module |
| Product Type | Communication Interface Module |
| Manufacturer | ProSoft Technology |
| Compatible Platform | Allen-Bradley CompactLogix / Compact GuardLogix |
| Primary Function | Provides Modbus TCP/IP Client and Server communication for CompactLogix PLCs |
| Communication Protocols | Modbus TCP/IP, Modbus Ethernet |
| Module Type | Single-slot communication module |
| Ethernet Ports | 1 × 10/100 Base-T RJ45 Ethernet port |
| Network Speed | 10/100 Mbps auto-sensing |
| Communication Modes | Modbus TCP Client and Server |
| Supported Connections | Multiple simultaneous Ethernet sessions |
| Supported Function Codes | 1, 2, 3, 4, 5, 6, 15, 16, 17, 22, 23 |
| Data Mapping | Up to 5000 user-definable registers |
| Backplane Compatibility | CompactLogix local chassis |
| LED Indicators | Module status and Ethernet activity LEDs |
| Configuration Method | ProSoft Configuration Builder / Studio 5000 integration |
| Isolation | Optical isolation between Ethernet interface and backplane |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Shock Resistance | 30 g operational |
| Vibration Resistance | 5 g from 10–150 Hz |
| Mounting Type | CompactLogix chassis slot |
| Protection Rating | Industrial enclosure environment |
| Dimensions (L × W × H) | Approx. 120 × 35 × 105 mm |
| Weight | Approx. 0.25 – 0.4 kg |
| Typical Applications | Modbus TCP/IP integration, SCADA systems, industrial Ethernet communication, remote I/O networking |
FAQ
What is the MVI69E-MBTCP used for?
It enables Allen-Bradley CompactLogix PLCs to communicate with Modbus TCP/IP devices over Ethernet networks.
What communication modes are supported?
It supports both Modbus TCP Client and Server communication modes.
Does it support multiple Ethernet connections?
Yes, it supports multiple simultaneous Modbus TCP/IP sessions.
Which PLC platform is it compatible with?
It is compatible with Allen-Bradley CompactLogix and Compact GuardLogix systems.
What type of Ethernet port is included?
It includes one 10/100 Mbps RJ45 Ethernet port.
Where is it commonly used?
It is widely used in SCADA systems, industrial automation, and Ethernet-based Modbus integration applications.
Allen Bradley MVI69E-MBS Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
