GE Fanuc IC693CHS391J 10-Slot Expansion Baseplate
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693CHS391J |
| Product Series | GE Fanuc Series 90-30 |
| Product Type | 10-Slot Expansion Baseplate |
| Module Function | Provides a mounting platform and backplane connection for Series 90-30 CPU, power supply, I/O, and option modules |
| Baseplate Type | Expansion baseplate |
| Number of Slots | 10 slots |
| Slot Configuration | Dedicated power supply slot with additional module slots for CPU, I/O, and communication modules |
| CPU Support | Compatible with Series 90-30 CPU modules and expansion configurations |
| Available I/O Slots | Up to 9 module positions depending on system configuration |
| Connector Type | 25-pin expansion connector |
| Expansion Connection | Supports connection with additional Series 90-30 expansion racks |
| Backplane Voltage | 5 VDC |
| Internal Power Consumption | Approximately 420 mA from 5 VDC supply |
| Communication Interface | Expansion rack connection interface |
| Installation Method | Panel-mounted PLC rack installation |
| Baseplate Addressing | Hardware-configured system addressing |
| Compatibility | GE Fanuc Series 90-30 PLC systems |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Dimensions | Approximately 443 × 130 × 142 mm (17.44 × 5.12 × 5.59 in) |
| Weight | Approximately 1.0 kg (2.2 lb) |
| Typical Applications | PLC system expansion, additional I/O capacity, industrial machine control, and distributed automation systems |
FAQ
Q1: What is the main function of the IC693CHS391J?
A: The IC693CHS391J is a 10-slot expansion baseplate designed for GE Fanuc Series 90-30 PLC systems. It provides mechanical mounting and electrical backplane connections for PLC modules.
Q2: How many modules can be installed on the IC693CHS391J?
A: The baseplate provides 10 slots. The power supply occupies the dedicated power slot, while the remaining slots can be used for compatible CPU, I/O, and option modules.
Q3: Can the IC693CHS391J be used as an expansion rack?
A: Yes. The IC693CHS391J is designed for expanding Series 90-30 PLC systems and can increase the available module capacity of the control system.
Q4: What types of modules are compatible with the IC693CHS391J?
A: The baseplate supports compatible Series 90-30 discrete I/O modules, analog modules, communication modules, and other supported option modules.
Q5: How is the IC693CHS391J connected to other PLC racks?
A: The baseplate uses an expansion connector interface to connect with compatible Series 90-30 racks through dedicated expansion cables.
Q6: Does the IC693CHS391J provide power to installed modules?
A: The baseplate distributes power from the installed Series 90-30 power supply module through the backplane to connected modules.
Q7: What should be checked before replacing an IC693CHS391J?
A: Confirm rack configuration, installed module types, power supply capacity, expansion connections, hardware addressing, and PLC system compatibility before replacement.
Q8: What are common applications for the IC693CHS391J?
A: The baseplate is commonly used in industrial automation systems requiring additional I/O modules, larger PLC architectures, machine control expansion, and distributed control applications.
