GE Fanuc IC693MDL730E Discrete DC Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693MDL730E |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | Series 90-30 PLC |
| Product Type | Discrete DC Output Module |
| Main Function | Provides 8-channel digital DC transistor output control for driving external field devices |
| Application | Industrial automation, machine control, solenoid control, relay control, motor starter control, indicator control |
| Output Type | Transistor output |
| Logic Type | Positive logic (Sourcing output) |
| Number of Outputs | 8 points |
| Output Configuration | 1 group of 8 outputs |
| Rated Output Voltage | 12/24 VDC |
| Output Voltage Range | 10.2–30 VDC |
| Output Current Rating | 2.0 A maximum per point |
| Total Output Current | 8 A maximum per module group |
| Output Load Type | DC resistive, inductive loads with proper suppression |
| Output Response Time | ON: 2 ms maximum / OFF: 2 ms maximum |
| Output Voltage Drop | 1.2 V maximum |
| Output Leakage Current | 1 mA maximum |
| Inrush Current Capability | 9.4 A maximum for 10 ms |
| External Power Supply | 12/24 VDC field supply required |
| Backplane Current Consumption | Approximately 55 mA at 5 VDC |
| Isolation Type | Optical isolation between field side and logic side |
| Isolation Voltage | 1500 VAC |
| Protection Function | Replaceable fuse protection for output groups |
| Fuse Configuration | Two 5 A fuses for output protection |
| LED Indicators | Individual output status LEDs and fuse fault indicator |
| Mounting Type | Series 90-30 PLC rack mounting |
| Installation Position | Any available I/O slot of Series 90-30 baseplate |
| Terminal Connection | Removable terminal block |
| Compatible Modules | GE Fanuc / Emerson Series 90-30 CPU, power supply, and I/O modules |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 130 mm × 125 mm × 35 mm |
| Weight | Approximately 0.34 kg |
| Compatibility | GE Fanuc / Emerson Series 90-30 PLC systems |
FAQ
Q1: What is the main function of the IC693MDL730E?
A: The IC693MDL730E is a Series 90-30 12/24 VDC positive logic output module used to control external DC devices such as solenoids, relays, motor starters, and indicators.
Q2: How many output points does the IC693MDL730E provide?
A: The module provides 8 digital DC output points in one group.
Q3: What type of output does the IC693MDL730E use?
A: It uses positive logic (sourcing) transistor outputs, supplying current from the positive power supply to connected loads.
Q4: What voltage and current can the outputs handle?
A: Each output supports 12/24 VDC operation with a maximum load current of 2 A per point.
Q5: Does the IC693MDL730E require an external power supply?
A: Yes. A separate 12/24 VDC field power supply is required to drive external loads.
Q6: Does the IC693MDL730E provide output protection?
A: Yes. The module includes fuse protection for output groups and provides fault indication through LED indicators.
Q7: What should be checked before replacing an IC693MDL730E?
A: Verify Series 90-30 compatibility, output voltage requirements, load current, external DC supply, fuse condition, wiring connections, and PLC configuration.
Q8: How can the reliability of the IC693MDL730E be maintained?
A: Use correct DC power wiring, install suppression devices for inductive loads, avoid exceeding output current ratings, keep terminals secure, and maintain proper cabinet conditions.
