GE Fanuc IC693MDL753F DC Discrete Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693MDL753F |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | Series 90-30 |
| Product Type | DC Discrete Output Module |
| Main Function | Provides 32-channel 12/24 VDC positive logic transistor outputs for controlling DC field devices |
| Application | Industrial automation, machine control, solenoid control, relay driving, indicator control, and distributed control systems |
| Output Type | DC transistor output |
| Logic Type | Positive logic (sourcing output) |
| Number of Outputs | 32 output points |
| Output Configuration | Four groups of 8 outputs each |
| Rated Output Voltage | 12/24 VDC |
| Output Voltage Range | 10.2 to 28.8 VDC |
| Output Current | 0.5 A maximum per point |
| Maximum Current per Group | 4 A maximum per output group |
| Maximum Common Current | 3 A per group common terminal |
| Inrush Current | 5.4 A for 10 ms |
| Output Voltage Drop | 0.3 VDC maximum |
| OFF-State Leakage Current | 0.1 mA maximum |
| ON Response Time | 0.5 ms maximum |
| OFF Response Time | 0.5 ms maximum |
| Isolation Type | Optical isolation |
| Isolation Rating | 1500 VAC field side to logic side; 250 VAC between output groups |
| External Power Supply | Required 12/24 VDC field supply |
| Backplane Power Consumption | Approximately 260 mA from 5 VDC backplane supply |
| LED Indicators | Individual output status LEDs |
| Terminal Connection | Two 24-pin connectors |
| Mounting Type | Series 90-30 baseplate I/O slot mounted |
| Dimensions | 140 mm × 140 mm × 46 mm |
| Module Weight | Approximately 220 g |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Compatibility | GE Fanuc Series 90-30 PLC systems |
FAQ
Q1: What is the main function of the IC693MDL753F?
A: The IC693MDL753F is a Series 90-30 32-point DC output module used to control external 12/24 VDC field devices through positive logic transistor outputs.
Q2: How many output channels does the IC693MDL753F provide?
A: The module provides 32 discrete output points divided into four groups of eight outputs.
Q3: What type of loads can the IC693MDL753F control?
A: It can control DC loads such as solenoid valves, relays, indicator lamps, actuators, and other industrial DC devices within the rated current range.
Q4: What voltage does the IC693MDL753F support?
A: The module supports 12/24 VDC positive logic outputs with an operating voltage range of approximately 10.2 to 28.8 VDC.
Q5: Is an external power supply required for the IC693MDL753F?
A: Yes. The output loads require an external 12/24 VDC field power supply.
Q6: What should be checked before replacing an IC693MDL753F module?
A: Confirm Series 90-30 compatibility, output voltage requirements, field wiring, connector condition, load current ratings, and PLC configuration before replacement.
Q7: What factors may affect IC693MDL753F performance?
A: Excessive load current, incorrect polarity, unstable field power, wiring faults, electrical noise, and insufficient protection may affect output reliability.
Q8: How can the reliability of the IC693MDL753F be maintained?
A: Maintain correct wiring, keep output loads within rated limits, inspect connectors regularly, ensure proper cabinet conditions, and perform routine PLC diagnostics.
GE Fanuc IC693MDL753F DC Discrete Output Module is in stock. Please contact us for a quick quote and competitive pricing.
