GE Fanuc IC693MDL930H Isolated Relay Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693MDL930H |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | Series 90-30 |
| Product Type | Isolated Relay Output Module |
| Main Function | Provides individually isolated relay outputs for switching AC and DC field loads |
| Application | Industrial automation, machine control, motor starter control, solenoid control, indicator control, and process equipment |
| Output Type | Relay output |
| Relay Contact Type | Form A (SPST), Normally Open (N.O.) |
| Number of Outputs | 8 output points |
| Output Configuration | 8 individually isolated relay circuits |
| Rated Output Voltage | 24 VDC / 120 VAC / 240 VAC |
| Output Voltage Range | 5 to 30 VDC / 5 to 250 VAC |
| Output Current Rating | 4 A maximum per point (resistive load) |
| Pilot Duty Current | 2 A maximum per point |
| Minimum Load Current | 10 mA |
| Maximum Inrush Current | 5 A |
| Switching Frequency | 20 cycles/minute maximum |
| Output Response Time | ON: 15 ms maximum; OFF: 15 ms maximum |
| Isolation Type | Individual point-to-point relay isolation |
| Isolation Rating | 1500 VAC field side to logic side; 1500 VAC point-to-point |
| LED Indicators | Individual output status LEDs |
| Backplane Power Consumption | Approximately 6 mA from 5 VDC bus (all outputs ON) |
| Relay 24V Bus Current | Approximately 70 mA (all outputs ON) |
| External Power Supply | Required for connected field loads |
| Terminal Connection | Removable terminal block |
| Mounting Type | Series 90-30 baseplate I/O slot mounted |
| Installation Position | Any available I/O slot in compatible Series 90-30 rack |
| Module Width | Single slot |
| Compatible Loads | Solenoids, contactors, motor starters, lamps, and other AC/DC loads |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 130 mm × 51 mm × 127 mm |
| Weight | Approximately 0.45 kg |
| Compatibility | GE Fanuc Series 90-30 PLC systems |
FAQ
Q1: What is the main function of the IC693MDL930H?
A: The IC693MDL930H is a Series 90-30 isolated relay output module used to switch external AC or DC loads through eight individually isolated relay contacts.
Q2: How many output channels does the IC693MDL930H provide?
A: The module provides 8 isolated relay output channels.
Q3: What voltage range does the IC693MDL930H support?
A: The module supports 5–30 VDC and 5–250 VAC loads, including common 24 VDC, 120 VAC, and 240 VAC applications.
Q4: What type of devices can be controlled by the IC693MDL930H?
A: It can control industrial devices such as solenoid valves, contactors, motor starters, indicator lamps, and other relay-controlled loads.
Q5: Are the relay outputs individually isolated?
A: Yes. Each output point is individually isolated, allowing separate field circuits to be controlled independently.
Q6: What should be checked before replacing an IC693MDL930H module?
A: Verify Series 90-30 compatibility, output voltage requirements, relay load current, field wiring, terminal connections, and PLC configuration before replacement.
Q7: What factors may affect the performance of the IC693MDL930H?
A: Excessive switching frequency, overloaded relay contacts, incorrect wiring, unstable field power, and inductive load surges may reduce relay life and reliability.
Q8: How can the reliability of the IC693MDL930H be maintained?
A: Keep loads within rated limits, use proper surge suppression for inductive loads, inspect terminals regularly, maintain suitable cabinet conditions, and perform routine PLC diagnostics.
GE Fanuc IC693MDL930H Isolated Relay Output Module is in stock. Please contact us for a quick quote and competitive pricing.
