GE Fanuc IC695CHS007 7-Slot Universal PLC Backplane
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||

Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | IC695CHS007 Universal Backplane |
| Manufacturer | Emerson Electric Co. (PACSystems / formerly GE Fanuc) |
| Product Type | 7-Slot Universal PLC Backplane |
| Series | PACSystems RX3i |
| System Compatibility | RX3i PLC modules, Series 90-30 I/O and option modules |
| Slot Configuration | Slot 0: Power supply only; Slots 1–5: PCI + serial I/O; Slot 6: PCI only |
| Bus Architecture | PCI bus + High-speed serial backplane |
| Power Requirements (internal) | 600 mA @ 3.3 VDC; 240 mA @ 5 VDC |
| Input Power | +24 VDC (auxiliary terminal strip) |
| Mounting Type | Rack / panel mounted (horizontal orientation) |
| Material / Build | Industrial-grade reinforced PCB and metal chassis |
| Operating Temperature | -20°C to +60°C (typical industrial rating) |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 141.4 mm × 264.9 mm × 147.3 mm (H × W × D) |
| Weight | Approx. 1.0–1.6 kg (varies by revision and packaging) |
| Clearance Requirement | Minimum 102 mm (4 in) on all sides |
| Protection Rating | IP20 (requires enclosure for harsher environments) |
| Grounding | Integrated grounding bar + grounding point |
| Installation | DIN/rack backplane mounting, fixed installation |
FAQ
Q1: What is the IC695CHS007 used for?
A: It is a 7-slot universal backplane used in RX3i PLC systems to connect and organize CPU, I/O, and communication modules.
Q2: Which PLC platforms are compatible with this backplane?
A: It supports PACSystems RX3i modules and selected Series 90-30 I/O and option modules.
Q3: How many modules can be installed?
A: Up to seven modules, including one dedicated power supply slot.
Q4: Can all slots be used for any module type?
A: No. Slot 0 is reserved for power supply, Slot 6 is PCI-only, and Slots 1–5 support both PCI and serial modules.
Q5: What is the installation orientation requirement?
A: The backplane must be installed horizontally in a rack or control cabinet.
Q6: Is external power required?
A: Yes, it uses +24 VDC auxiliary input for specific module and system functions.
Q7: What environmental protection level is required?
A: The unit is rated IP20 and should be installed inside an appropriate industrial enclosure.
Q8: What happens if the clearance requirements are not followed?
A: Insufficient spacing may cause overheating, reduced reliability, or system instability under continuous industrial load.
