GE Fanuc IC695CHS012-CA Universal Backplane Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC695CHS012-CA |
| Product Type | Universal Backplane Module |
| Series Compatibility | GE Fanuc PACSystems RX3i PLC System |
| Module Function | Provides mounting structure and high-speed communication platform for RX3i CPU, I/O, and option modules |
| Number of Slots | 12 slots |
| Backplane Type | Universal backplane with dual-bus architecture |
| Supported Bus Types | PCI-based high-speed bus and serial backplane bus |
| Compatible Modules | RX3i IC695 series modules and compatible IC694 series modules |
| Baseplate Type | Controller baseplate and expansion baseplate |
| Hot-Swap Support | Supported with compatible RX3i modules |
| Internal Power Consumption | Approx. 240 mA at 5 VDC and 600 mA at 3.3 VDC |
| Power Distribution | Provides backplane power distribution for installed modules |
| Module Communication | High-speed serial and PCI backplane communication |
| Installation Method | Rack-mounted installation in PACSystems RX3i control system |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions | Approx. 141.4 mm × 457.2 mm × 147.3 mm |
| Weight | Approx. 1.60 kg |
| Protection Rating | IP20 |
| Application Areas | Industrial automation, process control, distributed I/O systems, and complex PLC control platforms |
| Reliability Features | Provides stable module connectivity, fast data communication, and flexible system expansion capability |
FAQ
Q1: What is the IC695CHS012-CA used for?
- The IC695CHS012-CA is a 12-slot universal backplane designed for GE Fanuc PACSystems RX3i PLC systems. It provides the mounting interface and communication connection between the CPU, I/O modules, and communication modules.
Q2: How many modules can be installed on the IC695CHS012-CA?
- The backplane provides 12 available slots, allowing multiple RX3i modules to be installed in a single control rack.
Q3: What modules are compatible with the IC695CHS012-CA?
- The backplane supports RX3i IC695 series modules and selected compatible IC694 series modules through its universal backplane design.
Q4: What communication architecture does the IC695CHS012-CA use?
- The module uses a dual-bus architecture that supports PCI-based high-speed communication and serial backplane communication for flexible system integration.
Q5: What are the power requirements of the IC695CHS012-CA?
- The backplane requires system power distribution for installed modules and consumes approximately 240 mA at 5 VDC and 600 mA at 3.3 VDC for internal operation.
Q6: Can the IC695CHS012-CA be used for system expansion?
- Yes. It can be used as part of an RX3i control or expansion configuration to increase the number of available modules in larger automation systems.
Q7: What applications commonly use the IC695CHS012-CA?
- It is commonly used in factory automation, process control, manufacturing systems, distributed I/O applications, and large-scale PLC installations.
Q8: What should be checked before replacing an IC695CHS012-CA?
- Users should verify RX3i system compatibility, slot requirements, power capacity, module configuration, firmware compatibility, and installation conditions before replacement.
GE Fanuc IC695CHS012-CA Universal Backplane Module is in stock. Please contact us for a quick quote and competitive pricing.
