GE Fanuc IC697ALG230F PLC Analog Input Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | IC697ALG230F Analog Input Base Converter Module |
| Manufacturer | Emerson Electric Co. (formerly GE Fanuc Automation) |
| Product Type | PLC Analog Input Module |
| Series | GE Fanuc Series 90-70 |
| Function | High-level analog input conversion module (F revision) |
| Channels | 8 differential analog input channels |
| Input Signal Types | Voltage: 0–10 V / ±10 V; Current: 4–20 mA / 0–20 mA |
| Resolution | 14-bit to 16-bit (system dependent scaling) |
| Input Configuration | Individually configurable per channel (no DIP switches) |
| Expander Support | IC697ALG440 (current expander), IC697ALG441 (voltage expander) |
| Update Rate | Fast scan analog conversion (cycle time dependent on CPU scan) |
| Input Impedance | Voltage: >10 MΩ; Current: ~250 Ω (typical) |
| Isolation | Channel-to-backplane isolation (industrial grade, ~1500 VAC typical) |
| Backplane Interface | Series 90-70 rack backplane |
| Slot Requirement | 1 slot |
| Power Consumption | ~5 VDC backplane powered (~4–5 W typical) |
| Diagnostics | Open wire, overrange, underrange, module fault detection |
| Configuration Tool | Proficy Machine Edition / legacy configuration software |
| Revision Type | “F” revision hardware update (improved reliability / internal PCB revision) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Weight | Approx. 0.5 kg (≈ 1.1 lbs) |
| Dimensions | Approx. 4.6 cm × 29.2 cm × 22.9 cm (≈ 1.8 in × 11.5 in × 9.0 in) |
FAQ
Q1: What is IC697ALG230F used for?
A: It is an 8-channel analog input base converter module used in GE Fanuc Series 90-70 PLC systems for converting analog voltage or current signals into digital data for the CPU.
Q2: What does the “F” suffix mean?
A: The “F” indicates a hardware revision update of the IC697ALG230 module, typically improving internal reliability or manufacturing design while keeping the same functional behavior.
Q3: What input signals does it support?
A: It supports 0–10 V, ±10 V voltage inputs and 4–20 mA or 0–20 mA current loop signals.
Q4: How many channels does it have?
A: It provides 8 differential analog input channels.
Q5: Does it require configuration switches?
A: No, configuration is software-based; there are no DIP switches or jumpers.
Q6: What is the main difference between IC697ALG230 and IC697ALG230F?
A: Functionally they are very similar; the “F” version is a revised hardware iteration with updated internal design and improved robustness.
Q7: What is the typical weight of IC697ALG230F?
A: Approximately 0.5 kg (about 1.1 lbs).
Q8: Is IC697ALG230F still used today?
A: It is mainly used in legacy GE Fanuc Series 90-70 installations rather than new PLC systems.
