GE Fanuc IC697MDL940 Relay Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IC697MDL940 |
| Product Type | Relay Output Module |
| Series | GE Fanuc Series 90-70 |
| Function | Mixed relay output module used to switch AC and DC field loads in PLC systems |
| Output Channels | 16 points |
| Output Configuration | 8 Form C (isolated) + 8 Form A (grouped) relay contacts |
| Output Voltage Range | 5–265 VAC / 5–125 VDC (depending on contact type) |
| Nominal Load Types | AC and DC mixed industrial loads |
| Output Current | Up to 2 A per point (typical), limited by load type |
| Grouping | 2 groups (Form A outputs grouped in sets of 4) |
| Switching Type | Electromechanical relay |
| Response Time | ~10 ms ON / ~10 ms OFF |
| Minimum Load | ~10 mA required for reliable contact operation |
| Backplane Power Consumption | ~750 mA at 5 VDC |
| Isolation | 1500 VAC field-to-backplane isolation |
| Protection | Built-in fusing and RC snubber circuits |
| Status Indicators | 16 LED indicators (one per output channel) |
| Contact Material | Silver alloy relay contacts |
| Expected Life | Up to millions of operations (load dependent) |
| Compatibility | GE Series 90-70 rack I/O system |
| Mounting Type | Single-slot rack-mounted module |
| Power Supply | 5 VDC via rack backplane |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (W × H × D) | Approx. 135 mm × 285 mm × 290 mm |
| Weight | Approx. 0.8–1.0 kg |
FAQ
What is IC697MDL940 used for?
It is a relay output module used in GE Fanuc Series 90-70 PLC systems to control both AC and DC field devices such as contactors, solenoids, lamps, and small motors.
What makes IC697MDL940 different from transistor output modules?
Unlike transistor outputs, it uses mechanical relay contacts, allowing it to switch both AC and DC loads with higher voltage flexibility.
How many output channels does it have?
It provides 16 outputs: 8 individually isolated Form C contacts and 8 Form A contacts arranged in groups.
What is the output voltage range?
It supports a wide range from 5 VAC up to 265 VAC and from 5 VDC up to 125 VDC depending on contact configuration.
Is IC697MDL940 suitable for inductive loads?
Yes, but inductive loads should be properly suppressed using external protection (snubbers or diodes) to extend relay life.
What is the switching speed?
Typical relay switching time is around 10 ms for both ON and OFF transitions.
Does it require external load power?
Yes. Field loads require external power; the module only provides dry contact switching.
Is IC697MDL940 still used today?
It is mainly found in legacy GE Fanuc Series 90-70 systems and is typically replaced during modernization or system migration projects.
