Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | IS200ESELH1AAA |
| Series | GE EX2100 Excitation System / Mark VI Speedtronic |
| Product Type | Exciter Selector Board (ESEL) |
| System Application | Turbine-generator excitation control system |
| Platform | EX2100 / Mark VI control architecture |
| Main Function | Selects and routes gate pulse control signals from controller to gate amplifier path |
| System Role | Signal routing interface between EMIO and EGPA/EHPA boards |
| Input Signals | Six logic-level gate pulse commands from EMIO board |
| Output Function | Distributes gate command signals to EGPA (power bridge firing control) |
| Controlled Devices | Up to 6 SCR gate channels (via EGPA interface) |
| Communication | Internal backplane communication within EX2100 rack |
| System Integration | Works with EMIO, EGPA, DSPX controller, EPDM power system |
| Architecture Support | Supports simplex and redundant (M1/M2/C) excitation configurations |
| Redundancy Logic | Controller C selects active M1 or M2 signal path |
| Signal Isolation | Electrical isolation via backplane and fanout circuits |
| Power Supply | +5 V DC (via system backplane) |
| Board Type | Industrial VME-style control PCB |
| Mounting Type | 6U rack-mounted module in control cabinet |
| Diagnostics | LED indicators (power, active, gating status) |
| Operating Environment | Power plant turbine / generator excitation systems |
| Operating Temperature | -40°C to +65°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (W × H × D) | Approx. 33 cm × 10 cm × 20 cm |
| Weight | Approx. 0.4–2 kg (varies by revision and source) |
FAQ
1. What is IS200ESELH1AAA used for?
It is used in GE EX2100 excitation systems to act as a selector and routing board for SCR gate pulse commands.
2. What is its main function?
It receives six logic-level gate commands from the EMIO board and routes them to the EGPA boards for SCR firing control.
3. Which system is it compatible with?
It is designed for GE EX2100 and Mark VI excitation control systems used in turbine-generator applications.
4. What is its role in redundancy?
It works with M1/M2 controllers, while controller C selects the active signal path for reliable operation.
5. What boards does it interface with?
It interfaces primarily with EMIO, EGPA/EHPA, and DSPX controller boards.
6. Does it directly drive SCRs?
No, it only routes logic signals; actual SCR firing is handled by EGPA/EHPA power amplifier boards.
7. What type of hardware is it?
It is a 6U industrial VME-style control board used in excitation control cabinets.
8. Why is this board important?
Because it ensures correct selection and distribution of gate control signals, which is critical for stable and synchronized generator excitation.
