GE Fanuc IS200TRLYH1B Relay Output Terminal Board
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IS200TRLYH1B |
| Manufacturer | GE Industrial Systems |
| Product Family | Mark VI Turbine Control System |
| Product Type | Relay Output Terminal Board |
| Module Type | TRLY Board |
| Function | Provides relay-based output interface for turbine control and protection circuits within the Mark VI system |
| Application | Gas Turbine Control, Steam Turbine Control, Generator Control, Industrial Automation |
| Input Signals | Control logic signals from Mark VI controllers (trip/enable/control commands) |
| Output Signals | Relay-switched discrete outputs for field devices, interlocks, and auxiliary systems |
| Signal Types | Digital/Discrete relay outputs (Form C contacts) |
| Channel Function | Relay Switching, Signal Distribution, Control Output Interface |
| Relay Configuration | Multiple Form C relays with fused and protected output branches |
| Signal Conditioning | Coil drive feedback, MOV suppression, isolation and protection circuitry |
| Field Interface | Industrial control loads, interlocks, auxiliary relays, turbine sequencing circuits |
| Communication Interface | Interfaces with Mark VI control modules (e.g., controller I/O backplane) |
| Isolation Type | Galvanic isolation via relay contacts and driver circuitry |
| Diagnostic Features | Voted coil drive feedback, relay status monitoring, fuse monitoring, board identification |
| Connector Type | Mark VI rack connectors and terminal blocks (system-specific backplane interface) |
| Mounting Type | Rack-mounted terminal/relay board (Mark VI cabinet system) |
| Power Supply | 24 VDC / system control power (varies by configuration) |
| System Compatibility | GE Mark VI turbine control systems |
| Redundancy Support | Supports simplex and redundant / TMR architectures depending on system configuration |
| Operating Temperature | 0°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Dimensions (H × W × D) | ~330 × 178 × 55 mm |
| Weight | ~1.4 kg |
| Typical Applications | Turbine sequencing, auxiliary control, interlocks, relay-based switching, control logic output expansion |
| Revision Level | H1B |
| Lifecycle Status | Obsolete / Legacy Product |
FAQ
Q1: What is the IS200TRLYH1B?
A1: The IS200TRLYH1B is a relay output terminal board used in GE Mark VI turbine control systems to switch and distribute control signals to external field devices.
Q2: What is its main function?
A2: It provides relay-based switching between Mark VI control logic and field equipment such as interlocks, auxiliaries, and control circuits.
Q3: What kind of outputs does it provide?
A3: It provides discrete Form C relay outputs capable of switching industrial control loads.
Q4: Is it part of turbine protection or control?
A4: It is primarily part of the control and sequencing layer, though it may interface with protection-related logic depending on system design.
Q5: Does it execute control logic itself?
A5: No. It only executes switching actions; all logic is generated by Mark VI controllers.
Q6: What diagnostic features are included?
A6: Features include relay status monitoring, coil drive feedback, fuse monitoring, and board-level identification.
Q7: What are typical applications?
A7: Turbine sequencing, auxiliary equipment control, interlocks, and relay-based signal expansion.
Q8: What does “TRLY” mean?
A8: “TRLY” refers to the relay output terminal board family used in GE Mark VI systems for discrete relay switching functions.
