HIMA F-BASE RACK 11 Expansion Rack
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | HIMA |
| Model | F-BASE RACK 11 |
| Product Type | Expansion Rack |
| Product Series | HIQuad X |
| Rack Function | Extension rack for expanding I/O and system-module capacity |
| Rack Format | 19-inch |
| Compatible System | HIMA HIQuad X |
| System Compatibility | H41X / H51X |
| I/O Module Capacity | 12 slots |
| System Module Capacity | 9 slots |
| Total Module Positions | 21 |
| Main Function | Provides additional rack space for compatible I/O and system modules |
| I/O Bus | Supports connection of the I/O bus within the HIQuad X architecture |
| System Bus Integration | Supports integration with the HIQuad X system bus architecture |
| Installation | 19-inch industrial control cabinet or rack system |
| Typical Applications | Safety Instrumented Systems, process safety, industrial automation and critical control |
| Rack Expansion | Used when additional I/O or system-module capacity is required |
| Dimensions | 19-inch |
| Weight | 0.8 kg |
FAQ
1. What is the main function of the HIMA F-BASE RACK 11?
The HIMA F-BASE RACK 11 is an expansion rack designed for the HIQuad X safety and control system. It provides additional installation positions for compatible I/O modules and system modules, allowing the control-system architecture to be expanded without replacing the existing base rack.
2. Which HIMA systems are compatible with the F-BASE RACK 11?
The F-BASE RACK 11 is designed for the HIQuad X architecture and is used with compatible H41X and H51X system configurations. Before installation, the rack configuration should be checked against the processor, I/O processing module, power supply and other system components being used.
3. How many module positions does the F-BASE RACK 11 provide?
The F-BASE RACK 11 provides 12 positions for I/O modules and 9 positions for system modules. This gives the rack a total of 21 module positions for the corresponding HIQuad X architecture.
4. Why is an expansion rack required in a HIQuad X system?
An expansion rack is used when the number of required I/O points or system modules exceeds the available capacity of the main rack. By adding an F-BASE RACK 11, additional compatible modules can be installed while maintaining the overall rack-based system architecture.
5. How does the F-BASE RACK 11 communicate with the rest of the HIQuad X system?
The expansion rack forms part of the HIQuad X rack architecture and provides the physical structure for the installed modules and their internal bus connections. The I/O processing module manages communication between the system buses and the I/O bus, allowing field I/O data to be exchanged with the processor modules.
6. What should be checked when installing an F-BASE RACK 11?
The rack should be installed in a suitable 19-inch cabinet or rack structure with adequate mechanical support and ventilation. The module arrangement, power-supply configuration, I/O processing module and bus connections should all match the applicable HIQuad X system design. Correct grounding and secure connections should also be verified before commissioning.
7. What problems can occur if the expansion rack is incorrectly configured?
Incorrect rack configuration can result in module communication faults, unavailable I/O channels, power-distribution problems or system diagnostic alarms. If a newly installed rack is not recognized correctly, check the rack wiring, module positions, power supply, I/O processing module and system configuration before replacing individual components.
8. Where is the HIMA F-BASE RACK 11 typically used?
The F-BASE RACK 11 is typically used in safety and critical industrial automation systems based on the HIQuad X platform. Typical applications include Safety Instrumented Systems (SIS), Emergency Shutdown (ESD), process control, industrial safety systems and other applications requiring expanded I/O capacity.
