Schneider ATV340D75N4E Variable-Speed Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Product Range | Altivar Machine ATV340 |
| Product Type | Variable-Speed Drive |
| Model | ATV340D75N4E |
| Rated Motor Power | 75 kW (Heavy Duty) / 90 kW (Normal Duty) |
| Motor Power | 100 hp (Heavy Duty) / 125 hp (Normal Duty) |
| Rated Supply Voltage | 380–480 V AC, 3-phase |
| Supply Frequency | 50–60 Hz ±5% |
| Nominal Output Current | 145 A |
| Continuous Output Current | 145 A at 4 kHz, Heavy Duty; 173 A at 4 kHz, Normal Duty |
| Maximum Output Voltage | 480 V |
| Maximum Output Frequency | 0.599 kHz |
| Switching Frequency | 1–8 kHz adjustable; 2.5–8 kHz with derating |
| Nominal Switching Frequency | 2.5 kHz |
| Communication Ports | Modbus Serial, Ethernet/IP, Modbus TCP |
| Physical Communication Interface | 2-wire RS-485, 3 × RJ45 |
| Optional Communication Modules | PROFINET, DeviceNet, CANopen, EtherCAT |
| EMC Filter | Integrated Class C3 |
| Protection Rating | IP20; UL Type 1 |
| Digital Inputs | 8 |
| Analog Inputs | 3 |
| Analog Outputs | 2 |
| Relay Outputs | 3 |
| Programmable Digital Outputs | 1 |
| Preset Speeds | Up to 16 |
| Control Profiles | Variable Torque, Constant Torque, Optimized Torque |
| Motor Control | Asynchronous Motor, Permanent Magnet Motor, Reluctance Motor |
| Braking | DC Injection; integrated brake chopper |
| Safety Functions | STO, SS1, SLS, Safe Brake Management |
| PID Control | Adjustable PID regulator |
| Cooling Method | Forced convection |
| Cooling Air Volume | 295 m³/h |
| Operating Position | Vertical ±10° |
| Operating Temperature Class | IEC 60721-3-3 Class 3C3 / Class 3S3 environmental conditions |
| Pollution Degree | 2 |
| Noise Level | 69.9 dB |
| Installation | Wall mounting |
| Standards | IEC 61800-3, IEC 61800-5-1, IEC 60721-3, IEC 61508, IEC 13849-1, UL 508C |
| Dimensions | 271 × 908 × 309 mm |
| Weight | 58.4 kg |
FAQ
1. What is the rated power of the Schneider ATV340D75N4E?
The ATV340D75N4E is rated for a 75 kW motor under Heavy Duty operation. It can also support a 90 kW motor under Normal Duty conditions. The appropriate duty rating should be selected according to the actual load profile and overload requirements.
2. What input power supply does the ATV340D75N4E require?
The drive is designed for a three-phase AC supply from 380 to 480 V, with a supply frequency of 50 to 60 Hz ±5%. The input supply should be properly matched to the drive rating and installation requirements.
3. What is the continuous output current of the ATV340D75N4E?
For Heavy Duty operation, the continuous output current is 145 A at a 4 kHz switching frequency. For Normal Duty operation, the continuous output current is 173 A at 4 kHz. The selected duty mode must correspond to the motor and application load.
4. Which communication protocols are supported by the ATV340D75N4E?
The standard drive supports Modbus Serial, Ethernet/IP, and Modbus TCP communication. Optional communication modules are available for networks such as PROFINET, DeviceNet, CANopen, and EtherCAT, allowing integration with different PLC and automation architectures.
5. Does the ATV340D75N4E have an integrated brake chopper?
Yes. The ATV340D75N4E includes an integrated brake chopper and supports DC injection braking. For applications involving frequent deceleration or high regenerative energy, the braking system should be configured according to the motor inertia and required stopping performance.
6. What motor control technologies can be used with the ATV340D75N4E?
The drive supports several motor control modes, including asynchronous motor control, permanent magnet motor control, and reluctance motor control. This allows the ATV340D75N4E to be applied to a broad range of industrial machine-drive applications.
7. What safety functions are available on the ATV340D75N4E?
The drive provides integrated safety functions including Safe Torque Off (STO), Safe Stop 1 (SS1), Safely Limited Speed (SLS), and Safe Brake Management. These functions can be used as part of a properly engineered machine safety system.
8. How can communication or control faults on the ATV340D75N4E be diagnosed?
Start by checking the drive fault code and status information, then verify the control wiring, 24 V control supply, communication cable, network configuration, and PLC communication parameters. For Modbus connections, check the node address, baud rate, parity, and termination. For Ethernet-based communication, verify the IP configuration and network status before investigating higher-level PLC or application settings.
