Schneider BMXFCW501S Shielded Cable Assemblies
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Shielded Cable Assembly |
| Model | BMXFCW501S |
| Product Range | Modicon X80 |
| Application | Modicon M340 I/O System |
| Accessory Type | Shielded preformed cordset with flying leads |
| Compatible Modules | BMXART0414, BMXART0814 |
| Electrical Connection | 1 × 40-way connector + 1 × free end with color-coded flying leads |
| Cable Type | Shielded cable |
| Cable Length | 5 m |
| Main Function | Provides a preassembled shielded connection between compatible Modicon X80 analog I/O modules and field devices |
| Signal Application | Analog I/O signal connection |
| Shielding Function | Helps reduce electromagnetic interference and maintain signal integrity |
| Wiring Configuration | 40-way module-side connector with color-coded flying leads |
| Wire Identification | Color-coded according to DIN 47100 |
| Installation | Direct connection to compatible 40-way I/O module |
| Maintenance | Check the connector, cable sheath, shield, flying leads, and termination points regularly |
| Replacement Requirement | Verify the model, module compatibility, connector type, cable length, and wiring configuration before replacement |
| Weight | 0.71 kg |
FAQ
1. What is the Schneider BMXFCW501S Shielded Cable Assembly?
The BMXFCW501S is a shielded preformed cordset for Schneider Electric Modicon X80 I/O systems. It provides a 40-way connection on the module side and color-coded flying leads on the field side for connecting compatible analog I/O equipment.
2. What is the main function of the BMXFCW501S?
It provides a ready-made connection between compatible Modicon X80 analog I/O modules and field devices. The shielded cable construction also helps reduce the impact of electrical interference on analog signal transmission.
3. Which Schneider Electric modules are compatible with BMXFCW501S?
The BMXFCW501S is compatible with Modicon X80 analog input modules including BMXART0414 and BMXART0814. The module reference and terminal assignment should be checked before installation to ensure the wiring configuration is correct.
4. What type of electrical connection does BMXFCW501S use?
The module side uses one 40-way connector, while the opposite end has color-coded flying leads. The flying leads provide flexible field termination and are intended to be connected according to the signal and terminal assignment of the analog I/O system.
5. Why is a shielded cable used for analog I/O signals?
Analog signals can be affected by electromagnetic noise from motors, variable-frequency drives, contactors, and power cables. The shield helps reduce unwanted interference when it is installed and terminated correctly, which can improve the stability and reliability of the transmitted signal.
6. What should be checked if an analog signal is unstable or incorrect?
Check that the 40-way connector is fully inserted and that the field-side conductors are connected to the correct terminals. Also inspect the shield termination, cable routing, grounding, and nearby sources of electromagnetic interference before checking the I/O channel configuration and field instrument.
7. Can the flying leads of BMXFCW501S be modified during installation?
The flying leads can be terminated according to the field wiring requirements, but the original conductor identification and signal assignment must be maintained. Any modification should preserve proper insulation, mechanical protection, and shield continuity to avoid wiring faults or additional electrical noise.
8. How should the BMXFCW501S be maintained?
Regular maintenance should include checking the 40-way connector for looseness, contamination, or damaged contacts and inspecting the cable sheath for cuts, crushing, or excessive bending. The flying leads and shield termination should also be checked, especially in environments with vibration or significant electrical interference.
Schneider BMXFCW501S Shielded Cable Assemblies is in stock. Please contact us for a quick quote and competitive pricing.
