Schneider HMIG5U22 Basic Unit
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Description |
|---|---|
| Brand | Schneider Electric |
| Model | HMIG5U22 |
| Product Name | Harmony GTU Open Box Basic Unit |
| Product Type | HMI Base Unit |
| Product Series | Harmony GTU |
| Operating System | Windows 10 IoT Enterprise, 32-bit |
| Processor | Intel x86, 1.33 GHz |
| Rated Supply Voltage | 12–24 V DC |
| Internal Memory | 4 GB RAM |
| Backup Memory | 512 KB NVRAM |
| Storage | 32 GB CFast card |
| Storage Slots | 1 × SD card slot, 2 × CFast card slots |
| Ethernet Interfaces | 2 × RJ45, 10/100/1000BASE-T |
| COM1 Serial Interface | RJ45, RS-485 |
| COM1 Transmission Rate | 2,400–115,200 bps |
| COM2 Serial Interface | 9-pin SUB-D, RS-232C / RS-422 / RS-485 |
| COM2 Transmission Rate | 2,400–115,200 bps |
| USB Interfaces | 3 × USB 2.0 Type-A, 1 × USB 2.0 Mini-B |
| Video Interface | DVI-D |
| Audio Interface | Microphone mini-jack |
| Additional Interfaces | Auxiliary terminal block |
| Supported Communication Protocols | Modbus, Modbus TCP/IP, Uni-Telway |
| Supported Software | Vijeo Designer Runtime, EcoStruxure Operator Terminal Expert Runtime, Internet Explorer, .NET Framework 4.0, multimedia player |
| Real-Time Clock | Built-in |
| Status Indicators | Multicolor LED |
| Cooling Method | Natural convection |
| Operating Temperature | 0–60°C |
| Compatible Product Series | Harmony GTU display modules |
| Dimensions | 188 × 45 × 131 mm |
| Weight | 0.9 kg |
| Typical Applications | Industrial HMI systems, PLC communication, process monitoring, machine control, and operator interfaces |
FAQ
Q1: What is the main function of the Schneider HMIG5U22 Basic Unit?
A: The HMIG5U22 is an open-box HMI processing unit in the Harmony GTU product family. It runs compatible HMI applications and communicates with PLCs and other industrial devices. A compatible display module is required for a complete operator interface.
Q2: Which operating system does the HMIG5U22 use?
A: The HMIG5U22 uses Windows 10 IoT Enterprise 32-bit. Its software environment supports compatible HMI runtime applications and selected Windows-based utilities. Confirm software and driver compatibility before making system changes.
Q3: Which HMI software is supported by the HMIG5U22?
A: The unit supports Vijeo Designer Runtime and EcoStruxure Operator Terminal Expert Runtime. The appropriate runtime depends on the application project and system configuration. Verify the required software version before commissioning or replacing the unit.
Q4: Which communication protocols are available on the HMIG5U22?
A: The HMIG5U22 supports Modbus, Modbus TCP/IP, and Uni-Telway. The protocol used in a project depends on the connected PLC, selected communication interface, and software configuration.
Q5: Can the HMIG5U22 communicate with third-party PLCs?
A: Yes, if the PLC supports a compatible protocol and interface. Ethernet can be used for Modbus TCP/IP communication, while the serial ports support compatible RS-485, RS-232C, or RS-422 connections. Correct addressing and communication parameters are essential.
Q6: What should be checked if the HMIG5U22 cannot communicate with a PLC?
A: Check the network or serial cable, IP address, PLC station address, selected interface, and protocol settings. For serial connections, verify the baud rate and other communication parameters. Also confirm that the correct driver is configured in the HMI application.
Q7: What is the purpose of the CFast storage card?
A: The CFast card provides storage for the operating system, applications, and associated system data. Back up important files before replacing or removing the card, and follow the proper shutdown procedure to avoid data corruption.
Q8: What should be considered when replacing an HMIG5U22?
A: Confirm compatibility with the installed Harmony GTU display module, communication wiring, software runtime, and existing HMI project. Back up the application and configuration data before replacement, then test power, communication, and application operation during commissioning.
Schneider HMIG5U22 Basic Unit is in stock. Please contact us for a quick quote and competitive pricing.
