Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | SR3B261B |
| Product Type | Modular Intelligent Relay |
| Product Series | Zelio Logic |
| Total I/O Points | 26 (16 inputs + 10 outputs) |
| Digital Inputs | 16 |
| Input Signal Type | Discrete |
| Rated Supply Voltage | 24 V AC |
| Supply Voltage Range | 20.4–28.8 V AC |
| Supply Frequency | 50/60 Hz |
| Input Current | 4.4 mA per input |
| Input Impedance | 4.6 kΩ |
| Number of Outputs | 10 |
| Output Type | Relay |
| Output Contact Type | Normally Open (NO) |
| Output Voltage Range | 24–250 V AC; 5–30 V DC |
| Output Thermal Current | 5 A for 2 outputs; 8 A for the other 8 outputs |
| Programming Languages | Ladder Logic (LD), Function Block Diagram (FBD) |
| Display | Integrated LCD display |
| Real-Time Clock | Yes |
| Program Capacity | Up to 240 ladder logic lines or 500 FBD blocks |
| Cycle Time | 6–90 ms |
| Program Memory Backup | Up to 10 years at 25°C |
| Power Consumption | 7.5 VA without expansion modules; 10 VA with expansion modules |
| Expansion Capability | Supports compatible Zelio Logic expansion modules |
| Mounting Type | 35 mm DIN rail or screw mounting |
| Protection Rating | IP40 front panel; IP20 terminal block |
| Operating Temperature | -20°C to +55°C |
| Dimensions | 124.6 × 107.6 × 59.5 mm |
| Weight | 0.4 kg |
FAQ
Q1: What is the main function of the Schneider SR3B261B intelligent relay?
A: The SR3B261B is a programmable smart relay designed for industrial and building automation. It can control equipment sequences, switching operations, timers, counters, and other logic-based processes without requiring a larger PLC system.
Q2: What power supply does the SR3B261B require?
A: The SR3B261B uses a 24 V AC supply and supports a voltage range of 20.4–28.8 V AC at 50/60 Hz. The supply must match the specified AC requirements; a 24 V DC supply should not be substituted.
Q3: What types of input signals does the SR3B261B support?
A: The relay provides 16 discrete inputs designed for 24 V AC signals. The input specifications include a nominal input current of 4.4 mA and an input impedance of 4.6 kΩ. Confirm the wiring and signal requirements before connecting field devices.
Q4: What output functions are available on the SR3B261B?
A: The unit provides 10 normally open relay outputs for switching compatible AC or DC loads. Output voltage limits are 24–250 V AC and 5–30 V DC. The allowable current depends on the specific output group and load conditions.
Q5: Which programming software is compatible with the SR3B261B?
A: Schneider Electric Zelio Soft 2 is used to create, edit, simulate, and transfer programs for compatible Zelio Logic smart relays. Check the software version and communication cable compatibility before connecting the relay to a computer.
Q6: Can the SR3B261B perform scheduled control operations?
A: Yes. The integrated real-time clock supports time-based automation, such as scheduled switching and programmed operating sequences. Configure the clock and program logic according to the application’s timing requirements.
Q7: Can the SR3B261B be expanded with additional I/O modules?
A: Yes, it supports compatible Zelio Logic expansion modules. Before adding an expansion unit, check the module’s compatibility, the permitted system configuration, and the additional power requirements.
Q8: What should be checked when replacing an existing SR3B261B relay?
A: Confirm the 24 V AC supply, 16-input and 10-output configuration, relay contact ratings, program compatibility, and expansion-module arrangement. Review the wiring diagram and test the control sequence before returning the equipment to normal operation.
