Siemens 1FK7063-5AF71-1DH5 Servo Motor
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model | 1FK7063-5AF71-1DH5 |
| Product Type | Servo Motor |
| Product Series | SIMOTICS S 1FK7 Compact |
| Motor Type | Permanent-Magnet Synchronous Servo Motor |
| Design | Compact |
| Rated Power | 2.29 kW |
| Rated Speed | 3,000 rpm |
| Rated Torque | 7.3 Nm |
| Rated Current | 5.6 A |
| Static Torque at 60 K | 9.1 Nm |
| Static Torque at 100 K | 11.0 Nm |
| Stall Current at 60 K | 6.6 A |
| Stall Current at 100 K | 8.0 A |
| Maximum Mechanical Speed | 7,200 rpm |
| Maximum Inverter Speed | 6,600 rpm |
| Maximum Torque | 35 Nm |
| Maximum Current | 28 A |
| Number of Poles | 8 |
| Torque Constant | 1.37 Nm/A |
| Voltage Constant at 20°C | 87.5 V/1000 rpm |
| Winding Resistance at 20°C | 0.65 Ω |
| Rotating Field Inductance | 7.7 mH |
| Electrical Time Constant | 11.8 ms |
| Mechanical Time Constant | 1.56 ms |
| Thermal Time Constant | 40 min |
| Rotor Moment of Inertia | 19.91 × 10⁻⁴ kg·m² |
| Shaft Torsional Stiffness | 35,000 Nm/rad |
| Cooling Method | Natural Cooling |
| Frame Size | 63 mm shaft-height frame |
| Shaft Height | 63 mm |
| Mounting Design | IM B5 (IM V1, IM V3) |
| Degree of Protection | IP65; drive-end flange IP67 |
| Shaft End | Plain Shaft |
| Holding Brake | With Holding Brake |
| Encoder System | Incremental Encoder |
| Encoder Resolution | 22-bit, 4,194,304 counts |
| Encoder Internal Resolution | 2048 S/R |
| Commutation Position Resolution | 11-bit |
| Temperature Monitoring | KTY84 Temperature Sensor in Stator Winding |
| Electrical Connectors | Rotatable Power and Signal Connectors |
| Housing Color | Anthracite RAL 7016 |
| Vibration Severity Grade | Grade A |
| Weight | 12.802 kg |
FAQ
1. What are the rated power, speed, and torque of the Siemens 1FK7063-5AF71-1DH5?
The Siemens 1FK7063-5AF71-1DH5 has a rated power of 2.29 kW, a rated speed of 3,000 rpm, and a rated torque of 7.3 Nm. These ratings are intended for servo applications requiring controlled speed and torque output. The actual operating point should be selected according to the load profile, acceleration requirements, duty cycle, and the specifications of the connected Siemens drive system.
2. What type of motor is the 1FK7063-5AF71-1DH5?
This model is a permanent-magnet synchronous servo motor from the SIMOTICS S 1FK7 Compact series. The motor is designed for closed-loop motion control and provides controlled torque and speed characteristics suitable for industrial automation. Its 63 mm shaft-height frame and natural cooling design make it suitable for a range of machine-axis applications.
3. What encoder system is used on the Siemens 1FK7063-5AF71-1DH5?
The 1FK7063-5AF71-1DH5 uses an incremental encoder system with a 22-bit resolution of 4,194,304 counts. The encoder has an internal resolution of 2048 S/R and provides an 11-bit commutation position signal. When commissioning the motor, the encoder configuration and feedback parameters should match the connected drive system to ensure accurate speed and position feedback.
4. Does the 1FK7063-5AF71-1DH5 have a holding brake?
Yes. This servo motor is equipped with a holding brake. The brake is particularly useful in applications where the motor must maintain its position while stopped, such as vertical axes and lifting mechanisms. The brake should be controlled according to the drive manufacturer’s recommended sequence so that the motor and mechanical load are not subjected to unnecessary shock during starting and stopping.
5. What is the maximum operating speed of the 1FK7063-5AF71-1DH5?
The maximum permissible mechanical speed is 7,200 rpm, while the maximum inverter speed is 6,600 rpm. These values represent upper operating limits rather than recommended continuous operating speeds. Actual speed selection should consider the drive configuration, load inertia, acceleration and deceleration requirements, mechanical resonance, and the operating conditions of the complete machine.
6. What are the maximum torque and current ratings of this servo motor?
The maximum torque is 35 Nm and the maximum current is 28 A. The rated torque is 7.3 Nm with a rated current of 5.6 A. The maximum values are intended for dynamic or short-term operating conditions such as acceleration and transient load changes. Continuous operation should remain within the applicable motor and drive thermal limits.
7. How is the 1FK7063-5AF71-1DH5 cooled and mounted?
The motor uses natural cooling and does not require a separate forced-air cooling unit under its standard cooling configuration. It uses IM B5 mounting and can also be installed in IM V1 and IM V3 positions. The motor has IP65 protection, with IP67 protection at the drive-end flange. Adequate clearance should be maintained around the motor to allow heat to dissipate effectively.
8. What applications are suitable for the Siemens 1FK7063-5AF71-1DH5?
The 1FK7063-5AF71-1DH5 is suitable for industrial motion-control applications that require accurate speed, torque, and position control. Typical applications include machine tools, packaging equipment, material-handling systems, production machinery, automated positioning mechanisms, and multi-axis systems. The combination of 2.29 kW rated power, 3,000 rpm rated speed, high-resolution encoder feedback, and a holding brake makes it suitable for servo axes where controlled dynamic performance is required.
