Siemens 6AG1055-1MB00-7BA2 Extension Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model | 6AG1055-1MB00-7BA2 |
| Product Type | Analog Input/Output Expansion Module |
| Product Series | SIPLUS LOGO! |
| Compatible Controller | Siemens LOGO! 8 |
| Standard Reference Model | 6ED1055-1MB00-0BA2 |
| Analog Inputs | 2 |
| Analog Outputs | 2 |
| Input Signal Type | Voltage and current |
| Voltage Input Range | 0–10 V DC |
| Current Input Range | 0/4–20 mA |
| Analog Output Signal | Voltage or current, depending on configuration |
| Voltage Output Range | 0–10 V DC |
| Current Output Range | 0/4–20 mA |
| Rated Supply Voltage | 12/24 V DC |
| Supply Voltage Range | 10.8–28.8 V DC |
| Mounting Type | 35 mm DIN rail |
| Protection Rating | IP20 |
| Conformal Coating | Yes |
| Operating Temperature | -40°C to +70°C |
| Application | Analog signal acquisition and output control |
| Dimensions | 35.5 × 90 × 58 mm |
| Weight | 0.167 kg |
FAQ
Q1: What is the main function of the Siemens 6AG1055-1MB00-7BA2 module?
A: The 6AG1055-1MB00-7BA2 is a SIPLUS LOGO! expansion module designed to provide additional analog signal processing capabilities. It supports analog input acquisition and analog output control in compatible LOGO! automation systems.
Q2: Which controller is compatible with this expansion module?
A: The module is intended for compatible Siemens LOGO! 8 controllers. Before installation, verify the controller version, firmware requirements, and permitted expansion configuration.
Q3: What types of analog input signals can the module process?
A: The module supports voltage signals from 0 to 10 V DC and current signals in the 0/4–20 mA range. The selected input configuration must match the connected sensor or transmitter.
Q4: What analog output signals does the module provide?
A: The module supports analog output signals for compatible control applications, including voltage and current signals. Confirm the exact output ranges, channel configuration, and load requirements in the product’s technical documentation before connecting actuators or other equipment.
Q5: What power supply does the 6AG1055-1MB00-7BA2 require?
A: The module is designed for 12 V DC or 24 V DC supply systems, with a stated operating range of 10.8–28.8 V DC. Follow the manufacturer’s wiring instructions and verify the supply requirements of the complete LOGO! system.
Q6: What is the purpose of the SIPLUS design?
A: SIPLUS products are designed for applications that require enhanced environmental tolerance compared with standard industrial modules. This model’s conformal coating and extended temperature specification help support operation in demanding environments, subject to the manufacturer’s installation requirements.
Q7: Can this module be used to control a variable-frequency drive or proportional actuator?
A: It may be suitable when the connected equipment accepts compatible analog reference signals, such as 0–10 V or 4–20 mA. Verify the drive or actuator’s input specifications and configure the LOGO! program and analog output accordingly.
Q8: What should be checked if an analog channel does not work correctly?
A: Check the channel configuration, signal type, wiring polarity, common reference connections, and supply voltage. For current loops, confirm that the circuit is wired correctly and that the transmitter and receiving channel use compatible current ranges. Also review the LOGO! program and diagnostic information.
