Siemens 6AG1055-1MA00-7BA2 Extension Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model | 6AG1055-1MA00-7BA2 |
| Product Type | Analog Input Expansion Module |
| Product Series | SIPLUS LOGO! |
| Compatible System | LOGO! 8 |
| Base Model | 6ED1055-1MA00-0BA2 |
| Number of Analog Inputs | 2 |
| Input Signal Type | Voltage and current |
| Voltage Input Range | 0–10 V DC |
| Current Input Range | 0/4–20 mA |
| Rated Supply Voltage | 12/24 V DC |
| Supply Voltage Range | 10.8–28.8 V DC |
| Typical Current Consumption | 30 mA |
| Resistance Temperature Sensor Input | Not supported |
| Mounting Type | 35 mm DIN rail |
| Module Width | 2 spacing units |
| Protection Rating | IP20 |
| Conformal Coating | Yes |
| Operating Temperature | -40°C to +70°C |
| Minimum Startup Temperature | -25°C |
| Dimensions | 35.5 × 90 × 58 mm |
| Weight | 0.133 kg |
FAQ
Q1: What is the main function of the Siemens 6AG1055-1MA00-7BA2 module?
A: The 6AG1055-1MA00-7BA2 is a SIPLUS LOGO! AM2 analog input expansion module. It adds two analog input channels to a compatible LOGO! 8 controller, allowing the system to acquire voltage and current signals from sensors and transmitters.
Q2: Which PLC or controller is compatible with this expansion module?
A: This module is designed for the Siemens LOGO! 8 system and is based on the standard 6ED1055-1MA00-0BA2 module. Confirm the specific LOGO! controller version and expansion configuration before installation.
Q3: What analog input signals does the module support?
A: The module supports voltage signals from 0 to 10 V DC and current signals in the 0/4–20 mA range. The sensor output type must match the selected input configuration.
Q4: What power supply is required for the 6AG1055-1MA00-7BA2?
A: The module supports 12 V DC and 24 V DC nominal supply systems, with a specified operating range of 10.8–28.8 V DC. Check the wiring diagram and supply requirements before connecting the module.
Q5: Can the module connect directly to a Pt100 temperature sensor?
A: No. The 6AG1055-1MA00-7BA2 does not provide direct resistance-temperature-detector inputs for Pt100 sensors. For temperature measurement, use a compatible temperature input module or a transmitter that converts the sensor signal into a supported voltage or current range.
Q6: What is the purpose of the conformal coating?
A: The conformal coating provides additional protection for the circuit board against environmental contamination and helps improve reliability in demanding operating conditions. It does not eliminate the need to follow the specified installation and environmental limits.
Q7: What is the operating temperature range of this SIPLUS module?
A: The specified operating temperature range is -40°C to +70°C, with a minimum startup temperature of -25°C. This extended temperature capability distinguishes the SIPLUS version from standard modules intended for less demanding environments.
Q8: What should be checked if the controller does not detect the expansion module?
A: Check that the LOGO! controller supports the module, the expansion connection is firmly seated, and the power supply is within the specified range. Also verify the system configuration and wiring, then consult the controller diagnostics for any module or communication errors.
