Siemens 6AG1123-2GB03-2AX0 VDC Logic I/O Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Model | 6AG1123-2GB03-2AX0 |
| Product Type | SIPLUS HMI KTP700 Basic Color PN Operator Interface |
| Product Family | SIPLUS Basic Panels, 2nd Generation |
| Base Model | 6AV2123-2GB03-0AX0 |
| Display Size | 7 inches |
| Display Type | TFT widescreen display with LED backlighting |
| Display Resolution | 800 × 480 pixels |
| Display Colors | 65,536 colors |
| Touchscreen | Analog resistive touchscreen |
| Function Keys | 8 programmable function keys |
| Industrial Ethernet Interface | 1 × Ethernet |
| USB Interface | 1 × USB, supports storage devices up to 16 GB |
| Communication Protocols | PROFINET, TCP/IP, EtherNet/IP, Modbus TCP/IP |
| PROFINET IO | Not supported |
| IRT | Not supported |
| PROFIBUS | Not supported |
| MPI | Not supported |
| Power Supply | 24 V DC |
| Typical Power Consumption | 5.5 W |
| User Memory | 10 MB |
| Processor | ARM |
| Real-Time Clock | Hardware and software clock |
| Buzzer | Yes |
| Front Protection Rating | IP65 |
| Installation Position | Vertical; portrait and landscape installation supported |
| Operating Temperature | -20 to +50 °C |
| Configuration Software | WinCC Basic V13 / STEP 7 Basic V13 or later |
| Special Design | SIPLUS conformal coating |
| Application | Machine operation, process visualization, alarm handling and parameter monitoring |
| Dimensions | 261 × 189 × 63 mm |
| Weight | 0.977 kg |
FAQ
1. What is the Siemens 6AG1123-2GB03-2AX0 used for?
The 6AG1123-2GB03-2AX0 is a SIPLUS HMI KTP700 Basic Color PN operator interface designed for industrial machine operation and process visualization. It provides a graphical interface for displaying process values, operating equipment, monitoring machine status, handling alarms and entering operating parameters.
2. What type of display and touch technology does this HMI use?
The panel features a 7-inch TFT widescreen display with LED backlighting and supports 65,536 colors. It uses an analog resistive touchscreen, which allows operators to interact directly with configured buttons, input fields, status indicators and other graphical HMI objects.
3. Which communication protocols are supported by the 6AG1123-2GB03-2AX0?
The HMI provides one Industrial Ethernet interface and supports PROFINET, TCP/IP, EtherNet/IP and Modbus TCP/IP communication. This allows the panel to be integrated into different industrial Ethernet architectures and communicate with compatible PLCs, controllers and automation devices.
4. Can the 6AG1123-2GB03-2AX0 communicate with a Siemens PLC?
Yes. The panel can be integrated with compatible Siemens PLC systems through PROFINET-based Ethernet communication. HMI tags can be linked to PLC variables so that process values, machine states, commands and alarm information can be exchanged between the controller and operator interface.
5. Which engineering software is used to configure this HMI?
The 6AG1123-2GB03-2AX0 can be configured using Siemens WinCC Basic and the corresponding STEP 7 Basic engineering environment. The HMI project can include screens, tags, alarms, buttons, input fields, user controls and other visualization objects required for machine operation.
6. Does the 6AG1123-2GB03-2AX0 support alarm and diagnostic functions?
Yes. The HMI can be configured to display process alarms and operating messages. Alarm objects can be linked to PLC conditions or process variables, allowing operators to identify abnormal machine conditions and acknowledge relevant messages from the operator interface.
7. What is the advantage of the SIPLUS conformal coating?
The SIPLUS version uses conformal coating to provide additional protection for the electronic components against demanding environmental conditions. This design improves suitability for industrial applications involving increased humidity, condensation and other environmental stresses, provided the specified operating conditions are maintained.
8. Can the 6AG1123-2GB03-2AX0 be used with EtherNet/IP or Modbus TCP systems?
Yes. In addition to PROFINET and standard TCP/IP functions, the specified HMI supports EtherNet/IP and Modbus TCP/IP. This allows it to be considered for automation systems that use different Ethernet-based controller architectures, provided the required communication drivers and project configuration are supported.
